Page 10
Page | 10
INSTALLATION (CONTINUED)
I
NSTALL
S
IDE
A
IR
D
UCTS
SRI20PF
Two (2) side air ducts are packed with the accessories of the SRI20PF. Install the air ducts from the
corner top and bottom hooks into the provided slots on the sides of the chamber. The SRI6PF
incubator does not use side ducts.
Figure 1: SRI20PF
Air Duct Panel
Note: The air duct panels play an important role maintaining even heat distribution inside the
SRI20PF
’s incubation chamber. Failure to install both air duct panels may adversely impact
the incubator’s temperature uniformity.
