Reznor SFT Parts Manuals - Manual (Page 5)

Form RZ-NA-P-FT/SFT, Page 4
Model FT Electrical Components (cont'd) - Refer to the illustration on page 3
30 45 60 30 45 60
5 1 -- -- -- --
5A Venter M otor 1 -- -- -- --
5B Venter Wheel 1 -- -- -- --
5C Venter M otor Plate 1 -- -- -- --
5D Venter M otor Plate Gasket 1 -- -- -- --
5E Secondary M otor Plate 1 -- -- -- --
5F Spacers 4 -- -- -- --
5G Venter Fan Blade 1 -- -- -- --
6 1 -- -- -- -- 176329 --
6A Venter M otor 1 -- -- -- -- 175987 --
M agnetek
#JA2N297
6B Venter Wheel 1 -- -- -- -- 135979 --
Revcor B506-
1005
6C Venter M otor Plate 1 -- -- -- -- 176311 --
6D Venter M otor Plate Gasket 1 -- -- -- -- 155651 --
6E Isolator, rubber w/brass insert 4 -- -- -- -- 113498 --
6F Isolator Plate 1 -- -- -- 176310 --
6G Venter Fan Blade 1 -- -- -- -- 68005 --
7 1 -- -- -- -- 62594 --
8 Flame Sensor, Channel Products #1259-85 1
9A 1
9B Spark Ignitor 1
Ignition Cable 1
10 Gas Valve Natural 1
Gas
Propane 1
Gas
11 Limit Control, Thermodisc #36T 1
(access by removing louvers)
12 Transformer, 30 VA, #4000-01M 04BB80 1
13 Ignition Control Board, J/C G861 1
14A up to 4000 ft 1 164672
TDI #PPS10027-
2731 (replaces
159180)
(replaces
148072)
(replaces
149879)
4001-9000 ft 164674
TDI #PPS10027-
2733 (replaces
159181)
(replaces
148072)
(replaces
159179)
14B up to 4000 ft 1 -- -- -- --
4001-9000 ft -- -- -- --
15 Silicone Rubber Tubing for Pressure 1 147905 147905
Sensing (not illustrated) 7 " long 9" lg 7 " long 9" long
16 Auxiliary Limit Control (remove fan guard to access) 1 -- -- -- -- -- --
17 Flame Rollout Switch (manual reset) Std FT & suffix CV 1 -- -- -- 121275, 275°F 112752, 225°F 121275, 275°F
M odel FT45-LN only -- -- -- -- 121275, 275°F --
18 Fan M otor - See Code 39C for standard M odel FT or M odel FT with suffix CV; see Code 40C for M odel FT with suffix LN
19 Outlet Box , 2x4, Steel City #58361 1 -- -- 17782 -- -- --
20 Outlet Box Cover 1 -- -- 17800 -- -- --
Apply to Model FT
with suffix LN
(Option AL2B)
Apply to Model FT
with suffix CV
(Option AV6)
Vntr M tr & Wheel Assy (includes Codes 6A-6G) - Size 45
heater with suffix LN (Option AL2B) only
Revcor B506-1005
177148
175987
135979
Code
Venter M tr & Wheel Assy (includes Codes 5A-5G) - Size
30 or 45 heater with suffix CV (Option AV6) only
Description (cont'd)
172552, M /H VR8105M 2187
147167
M agnetek #JA2N297
172553, M /H VR8105M 2825
Vntr Inlet Ring - Size 45 with suffix CV or LN only
Spark Ignitor with Cable - applies only to heaters with
Johnson Controls G861 Ignition Control Board, P/N 174260
(Code 13)
use w/RAM 3M C4
ignition cntrl board
NOTE: Identify the valve on the
heater by manufacturer's no. and the
Serial No. code on page 2.
Pressure Switch - applies to
standard heater (for Size 30 or 45
with suffix CV or LN, see Code 14B
TDI #PPS10027-2731
Pressure Switch - applies to Sizes
30 and 45 with Suffix CV or LN only
TDI #PPS10027-2733
164672
TDI #PPS10027-2228
TDI #PPS10027-2355
148072
164675, TDI #PPS10027-2734
174260 (replaces P/N 147102 and may be used with either Code 9A or 9B; if
replacing board and ignitor, order Code 9A)
For heaters mfgd PRIOR TO
residential approval (approx.
11/97*- verify on rating plate)
For heaters WITH residential approval (beginning
approx. 11/97* - verify on rating plate)
(replaces 147133, Robertshaw #7222 DER; field-supplied piping is required)
172553, M /H VR8105M 2825
(replaces 147134, Robertshaw #7222 DERLP; field-supplied piping is required)
180°F
147165
176311
147166
68005
147166
147167
45602
172552, M /H VR8105M 2187
147356
45602
180°F
147356
147904 147904
149879
164673, TDI #PPS10027-2732
164674
Qty
147165
159956 (assembly replaces both 147166 and 147167)
155651
176810
98872
