S5BP Series Replacement Parts List
ITEM DESCRIPTION
208-230V / 3 Ph. / 60HZ 460V / 3 Ph. / 60HZ
090C 120C 090D 120D
1 Fan Grill 669891 669891 669891 669891
2 Orifice, Fan, 30” Spun 2B5272 2B5272 2B5272 2B5272
3 Top Pan, 30” 2B5241 2B5241 2B5241 2B5241
4 Washer, Flat 612064 612064 612064 612064
5 Nut, Acorn 606253 606253 606253 606253
6 Fan Blade 667394 667399 667394 667399
7 Condenser Motor 622207R 622207R 622224R 622224R
8 Motor Mount, Basket 669854 669854 669854 669854
9 Motor Stand Off, .965" High 669903 669903 669903 669903
10 Base Rail, Long D09670 D09670 D09670 D09670
11 Base Rail, Short D09680 D09680 D09680 D09680
12 Base Rail, Middle (Not Shown) D09720 D09720 D09720 D09720
13 Bottom Pan D09650 D09650 D09650 D09650
14 Bracket, Valve Mount 295781 295781 295781 295781
15 Refrigerant Valve (Large) 664662R 664662R 664662R 664662R
16 Refrigerant Valve (Small) 663863 663863 663863 663863
17 Accumulator 669294 669294 669294 669294
18 Filter Dryer (Not Shown) 669892 669888 669892 669888
19 Compressor 920500 920489 920501 920490
20 Crankcase Heater 632345 632351 632346 632352
21 Grommet, Compressor 668530 668530 668530 668530
22 Bolt, Compressor 600400 600400 600400 600400
23 Outdoor Coil (Formed) 290127R 2B4923R 290127R 2B4923R
24 Repl, Hail Guard Kit (Not Shown) 669301R 669885R 669301R 669885R
25 Anti Short-Cycle Timer 621586 621586 621586 621586
26 Switch, High Pressure (Not Shown) 632473 632473 632473 632473
27 Switch, Low Pressure (Not Shown) 632361 632361 632361 632361
28 Contactor 621784 621784 621784 621784
29 Low Voltage Divider 258790 258790 258790 258790
30 Snap Bushing 631957 631957 631957 631957
31 Transformer 622247 622247 622247 622247
32 Control Panel Cover 389330 389330 389330 389330
33 Capacitor 622137 622137 622137 622137
34 Capacitor Strap 285931 285931 285931 285931
35 Control Panel 389340 389340 389340 389340
36 Access Panel 389360 2B4931 389360 2B4931
37 Corner Post 2A1051 2A1052 2A1051 2A1052
38 Motor Basket Clamp (Not Shown) 669346 669346 669346 669346
Please specify Model No., Serial No., and the correct part number(s) when ordering parts from the nearest authorized dealer or service center.
Specifications & illustrations subject to change without notice or incurring obligations.
O'Fallon, MO | Printed in U.S.A. (07/11)
709096A (Replaces 7090960)
