R6GP REPLACEMENT PARTS LIST - 3 PHASE UNITS, 7.5 TON & 10 TON

ITEM

DESCRIPTION

R6GP- 090* (FIGURE 2)

R6GP-120* (FIGURE 2)

208/230 V

460 V

208/230 V

460 V

Manifold, Gas

664312

664311

—

Orifice, Main Burner, #36 (Not Shown)

661036

Burner, Inshot

660907

HX Tube Assm

663731

663732

55a

Turbulator, HX Tube (Not Shown)

385600

Gasket, HX Tube Plate (Not Shown)

689525

Rail, Base - Heat Exchange End

289991R

Rail, Base - Front Right

292051R

Rail, Base - Back Right (Not Shown)

292061R

Rail, Base - Front Left

289631R

Rail, Base - Back Left (Not Shown)

289641R

Rail, Base - Condenser End

289621R

Condenser Coil Spacer

—

290841R

Crankcase Heater - 240V / 40 W, 1 Stage (Not Shown)

632541

—

632510

—

Crankcase Heater - 240V / 40 W, 2 Stage (Not Shown)

632542

—

632511

—

Crankcase Heater - 480V / 40 W, 1 Stage (Not Shown)

—

632543

—

632512

Crankcase Heater - 480V / 40 W, 2 Stage (Not Shown)

—

632544

—

632513

Compressor Bolt, 5/16-18 x 1-1/2”

600400

Compressor Mounting Grommet (Not Shown)

668530

Cap, Service Port, Brass

663818

Cover, Service Port Cap, Pink R-410a

664127

Filter Dryer, EK-16-3-S

—

669493

Filter Dryer, EK-08-3-S

669492

—

Vent Cover Assm, Inducer Exhaust

265240R

Filters 16 X 25 X 2 - U.L. Class (Not Shown)

—

668932

Filters 16 X 20 X 2 - U.L. Class (Not Shown)

668940

—

Bottom Power Entry Cover

263920R

Limit, Gas HX, 10T, Blower Outlet, Bottom

—

626474

Limit, Gas HX , 10T, Blower Outlet, Top

—

626483

Limit, Gas HX, 7.5T, Blower Outlet, Top

626485

—

Limit, Gas HX , 7.5T, Blower Outlet, Bottom

626576

—

Transformer, Auto Step-Down, 460V / 230V

—

621781

—

621781

Please specify the correct Model No., Serial No., and part no(s) when ordering parts from the nearest authorized dealer or service center.
