Q6SD Series Single Package Heat Pump
13 SEER, 460V, 3-Phase Models (Continued)
ITEM DESCRIPTION
Q6SD—X36D Q6SD—X48D Q6SD—X60D
919953 919954 919955
40 CONNECTOR, SWIVEL 664194 — —
41 CORE, PORT, HI FLOW, BRASS (NOT SHOWN) 664331 664331 664331
42
VALVE, TXV, EQ, CK, R410A, 3.0T, ID 664343 — —
VALVE, TXV, EQ, CK, R410A, 4.0T, ID — 664345 —
VALVE, TXV, EQ, CK, R410A, 5.0T, ID — — 664347
43
VALVE, TXV, EQ, CK, R410A, 4.0T, OD — 664346 —
VALVE, TXV, EQ, CK, R410A, 5.0T, OD — — 664348
44 FITTING, PANEL MNT, HI-FLOW, 3/8” 664393 664393 664393
45 WHEEL, BLOWER 10x10 667207 667207 667207
46
FAN, 3BL, 20.0D, 30P, CW, 1/2,1140 667278 667278 —
FAN, 4BL, 20.0D, 28P, CW, 1/2, 1140 — — 667282
47
ACCUM, 5”D, 3/4”, 124 IN3 668853 — —
ACCUM, 5”D, 7/8”, 174 IN3 — 668854 668854
48 PAN, DRAIN R4 / P4 / Q4 669190 669190 669190
49 REPLACEMENT HAIL GUARD KIT (NOT SHOWN) 917206 917206 917206
50 DRIER, FILTER, BIFLOW, 8 IN^3 669379 669379 669379
51 GRILLE, TOP-24” BLACK 669404 669404 669404
52
REVERSING VALVE 669465 — —
REVERSING VALVE KIT — M0079101R M0079101R
53 COIL, RV, (NOT SHOWN) 669472 — —
54 PAINT, STERLING GRAY, TOUCH UP (NOT SHOWN) 903598 903598 903598
55
PANEL, SERVICE D05112R — —
PANEL, SERVICE — D05113R D05113R
56 PANEL, ELECTRIC HEAT D05420 D05420 D05420
57 STAND, DRAIN PAN D05440 D05440 D05440
58 PANEL, BLOWER TRANS SIDE D05450 D05450 D05450
59 BOTTOM PAN ASSY. D05480R D05480R D05480R
60 DIVIDER PANEL ASSY. D05502R D05503R D05503R
61 DUCT CAP ASSY. D05530R D05530R D05530R
62 TOP PAN ASSYEMBLY - LEFT 293781R 293781R 293781R
63 PANEL, CLOSE-OFF ASSY. D05685R D05686R D05686R
64 COIL, OUTDOOR D06262R D06265R D06266R
65 POST, CORNER D09996R D09997R D09997R
66
MTR, X-13 PROG, Q6, 1/2HP M0002969R — —
MTR, X-13 PROG, P6, 3/4HP — M0023924R M0023924R
67 SET OF WIRES (NOT SHOWN) M0038359R M0038359R M0038359R
68 FILTER RACK ASSY. M0021601 M0021601 M0021601
70 LOW PRESSURE SWITCH(NOT SHOWN) 632393 632393 632393
71 COIL SUPPORT (NOT SHOWN) 263394 263394 263395
72 BRACKET, ELECTRIC HEAT 263860 263860 263860
73 DUCT COVER (NOT SHOWN) 284821 284821 284821
74 BRACKET, BLOWER HOUSING (NOT SHOWN) 295771 295771 295771
75
BRACKET, HAIL GUARD, LT (NOW SHOWN) 2A6811 2A6811 2A6811
BRACKET, HAIL GUARD, RT (NOT SHOWN) 2A6821 2A6821 2A6821
76 MOTOR MOUNTING ARM 668928 668928 668928
77 CONTROL BRACKET 298591 298591 298591
78 ONE-PIECE TOP PAN KIT (ORIFICE INCLUDED) M0034721 M0034721 M0034721
79 DROP-IN ORIFICE 263210 263210 263210
Please specify Model No., Serial No, and the correct part number(s) when ordering parts from the nearest authorized dealer or service center.
