Reznor P6SD - 460-3 Parts Manuals User Manual

Page 2

P6SD Series Single Package Air Conditioner

3-Phase Models

ITEM

DESCRIPTION

P6SD-X36D

P6SD-X48D

P6SD-X60D

919947

919948

919949

RAIL, BASE, 47.23” LG

277551

RAIL, BASE, 55.63” LG

277552

CHANNEL, DRAIN

279722R

PANEL, BLOWER TRANSITION

283941

283942

COIL, OUTDOOR

285821R

285831R

285841R

PANEL, FRONT

298892R

298893R

RETURN PANEL ASSY W/ACCESS DR

286702R

286701R

CONTROL PANEL ASSY

292406R

292407R

INSULATED TOP RIGHT PAN ASSY

292441R

BLOWER HSG ASSY, 10X8

297212

—

BLOWER HSG ASSY, 10X10

—

297214

BRACKET, EXT. SERVICE PORTS

298551R

DIVIDER, LOW VOLTAGE

2A9691

BRASS NUT, EXT. SERVICE PORT (NOT SHOWN)

618084

CONTACTOR, 3 POLE / 30A W/AUX. SW

621832

TRANSFORMER 40VA

621850

RELAY, DPDT, 24V COIL

624617

—

RELAY, SPDT, NO / NC, 20/10

—

621931

CAPAC, RUN 7.5/370-RND-PLST

622132

CAPAC, RUN 10/370-RND-PLST

622133

—

CAPAC, RUN 15/370-RND-PLST

—

622135

—

COMP, COPE, ZP31K5E-TFD-130

920137

—

COMP, COPE, ZP42K5E-TFD-130

—

920138

—

COMP, COPE, ZP54K5E-TFD-130

—

920139

MTR, FAN, PSC, K, 1/4

622422

BLOWER MOTOR 3/4HP

—

M0023924R

BLOWER MOTOR 1/4HP

622423

—

BLOWER MOTOR 1/2HP

—

622424

—

DUAL GROUNDING LUG

632235

FUSE, 3-AMP (NOT SHOWN)

632261

BLOCK, TERMINAL, 3-POLE

632348

SWITCH, HIGH PRESSURE (NOT SHOWN)

632401

HEATER, CRANKCASE, 480V / 40W, 60” (NOT SHOWN)

632576

PLUG, MOLDED, HV, TF5, 52” (NOT SHOWN)

634718

CORE, CHARGING PORT (NOT SHOWN)

662103

DIST, BODY, 5 CIR (NOT SHOWN)

663582

—

DIST, BODY, 8 CIR (NOT SHOWN)

—

663586

FITTING, ACCESS

663812

CAP, SERVICE PORT, BRASS (NOT SHOWN)

663818

Please specify Model No., Serial No, and the correct part number(s) when ordering parts from the nearest authorized dealer or service center.
