708825D (Replaces 708825C)
Specifications & illustrations subject to change without notice or incurring obligations.
O’ Fallon, MO | Printed in U.S.A. (10/12)
JT4BD-D Series Split System Heat Pump, 3-Phase, 13 SEER Models
CoMPoNENT
JT4BD-036D JT4BD-048D JT4BD-060D
920177J 920178J 920179J
Access Panel 274016R 274016R 274016R
Accumulator 668794 668854 668854
Capacitor 01-0021 01-0023 01-0023
Compensator Tank 669422 669422
Compressor 920137 920138 920139
Compressor Bolt 600426 600426 600426
Compressor Grommet 668530 668530 668530
Compressor Molded Plug 634692 634692 634692
Contactor 621667R 621667R 621667R
Control Box 2B7881 2B7881 2B7881
Control Box Cover 276921 276921 276921
Crankcase Heater 632108 632108 632108
Defrost Board 917178A 917178A 917178A
Defrost Sensor 626491R 626491R 626491R
Distributor 664718R 664719R 664719R
Filter Drier 669762 669761 669761
High Pressure Switch 632473R 632473R 632473R
Low Voltage Divider 258791 258791 258791
Motor Wire Conduit 664290 664290 664290
Muffler 669546R 669546R 669546R
Outdoor Coil 2C3331RD 2C3341RD 2C3341RD
Outdoor Coil Guard 2B6606R 2B6606R 2B6606R
Outdoor Fan Blade 667383 667383 667383
Outdoor Fan Grille 669335R 669335R 669335R
Outdoor Fan Motor 622321 622323 622323
Refrigerant Valve (LG) 663865R 663865R 663865R
Refrigerant Valve (SM) 664509R 664509R 664509R
Relay 624617R 624617R 624617R
Reversing Valve M0079102 M0079102 M0079102
Reversing Valve Coil 669937R 669937R 669937R
Schrader Fitting 664423 664423 664423
Top Pan 496162 496162 496162
Valve Core 662103R 662103R 662103R
Please specify Model No., Serial No, and the correct part number(s) when ordering parts from the nearest authorized dealer or service center.
