¢7088424¤

JS4BD-KA / KB Series Residential Split System Air Conditioner

ITEM DESCRIPTION 018KA/KB

024KA/KB

030KA/KB

036KA/KB

042KA/KB

048KA/KB 060KA/KB

2 Compressor

918867 919606 918869 918870

918871 918872 918873

3 Refrigerant

Valve

(Large)

663992 663992 663992 663992 663963 663963 663963

4 Refrigerant

Valve

(Small)

664255 664255 664255 664255 664255 664255 664255

5

Coil Guard (Formed, Streling Grey) - KA

275701R

275702R

275704R

275704R

275713R

275713R

275716R

Coil Guard (Formed, Streling Grey) - KB

275701R

275701R

275702R

275702R

275712R

275712R

275713R

Coil Guard (Formed, Bronze) - KA

2B6461B

2B6463B

2B6464B

2B6464B

2B6603B

2B6603B

2B6606B

Coil Guard (Formed, Bronze) - KB

275701R

275701R

275702R

275702R

275712R

275712R

275713R

6

Outdoor Coil (Formed) - KA

276361R

275273R

275274R

275274R

274521R

274521R

275283R

Outdoor Coil (Formed) - KB

2A0001R

2A0001R

2A0003R

2A0003R

2B5231R

2B5231R

2B5232R

7 Control

Box

277361 277361 277361 277361 277361 277361 277361

8 Low

Voltage

Divider

258790 258790 258790 258790 258790 258790 258790

9 Contactor

621661 621661 621661 621661 621662 621662 621662

10

Capacitor - KA

621969

620763

620763

621153

621153

621944

621717

Capacitor - KB

621969

620763

620763

621153

621153

621944

621944

11

Capacitor

strap

258781 258781 258781 258780 258780 258780 258780

12

Access Panel - KA

274011

274013

274014

274014

274013

274013

274016

Access Panel - KB

274011

274011

274012

274012

274012

274012

274013

13

Snap Bushing (not shown)

631323

631323

631323

631323

631323

631323

631323

14

Top

Pan

496161 496161 496161 496161 496162 496162 496162

15

Fan

Motor

621952 621919 621919 621917 621990 621990 621990

16

Fan

Blade

667315 667261 667261 667318 667316 667316 667316

17

Fan

Grille

669334 669334 669334 669334 669335 669335 669335

18

Motor wire conduit

664158

664158

664158

664158

664162

664162

664162

19

Nut, Double thick

606261

606261

606261

606261

606261

606261

606261

20

Control Box Cover

276921

276921

276921

276921

276921

276921

276921

21

Grommet,

Compressor

668530 668530 668530 668530 668530 668530 668530

22

Bolt, Compressor (metal)

600400

600400

600400

600400

600400

600400

600400

Bolt, Compressor (composite)

600426

600426

600426

600426

600426

600426

600426

23

High Press Switch (not shown)

632473

632473

632473

632473

632473

632473

632473

24

Filter Drier (not shown)

669378

669378

669378

669378

669378

669378

669378

25

Compressor molded plug (not shown)

634658

634658

634658

634659

634659

634660

634660

Please specify Model No., Serial No., and the correct part number(s) when ordering parts from the nearest authorized dealer or service center.

708842E (Replaces 708842D)

Specifi cations & illustrations subject to change without notice or incurring obligations.
O’ Fallon, MO | Printed in U.S.A. (11/10)
