7094360 (Replaces 708826B)
Specifications & illustrations subject to change without notice or incurring obligations.
O’ Fallon, MO | Printed in U.S.A. (03/13)
JS4BD-DB Series Residential Split System Air Conditioner
13 SEER , 3-Phase, 460V Models
DESCRIPTION 036DB 048DB 060DB
Bolt, Compressor (composite) 600426 600426 600426
Capacitor 01-0023 01-0023 01-0023
Capacitor strap 258781R 258781R 258781R
Coil Guard (Formed) 2B6462R 2B6603R 2B6603R
Compressor 920137 920138 920333
Compressor molded plug (not shown) 634692R 634692R 634692R
Contactor 621667R 621667R 621667R
Fan Blade 667396R 667383R 667383R
Fan Grille 669334R 669335R 669335R
Fan Motor 622322 622323 622323
Filter Drier (not shown) 669764 669764 669764
Grommet, Compressor 668530 668530 668530
High Press Switch ( not shown) 632473R 632473R 632473R
Outdoor Coil (Formed) 2A9972R 2B5232R 2B5232R
Refrigerant Valve (Large) 663864R 663865R 663865R
Refrigerant Valve (Small) 663862R 663862R 663862R
Top Pan 496161R 496162R 496162R
Please specify the correct Model No., Serial No., & part number(s) when ordering parts from the nearest authorized dealer or service
center.
