B5SM AIR HANDLER REPLACEMENT PARTS LIST
ITEM DESCRIPTION
208-230/460-3-60 208-230-1-60 208-230/460-3-60 208-230-1-60
090J 090K 120J 120K
28
Pulley, Blower, Drive, BK100 667366 667366 - - - - - -
Pulley, Blower, Drive, BK80 - - - - - - 667368 667368
29
Belt, Blower Drive, A36 669370 669370 - - - - - -
Belt, Blower Drive, A32 - - - - - - 669676 669676
30
Complete Coil Assy, 090 (TXV/Distributor
included)
297193R 297193R - - - - - -
Complete Coil Assy, 120 (Distributors
included, TXV not included)
- - - - - - 297192R 297192R
31 Key, Blower Shaft (Not Shown) 618057 618057 618057 618057
32
Blower Power Cord (Not Shown) 634696 634696
Blower Power Cord (Not Shown) 634695 - - - 634695
33
Grommet, Flexible, 3/8” (Not Shown) - - - - - - 689086 689086
Grommet, Flexible, 7/8” (Not Shown) 689089 689089 - - - - - -
Grommet, Flexible, 1” (Not Shown) 689977 689977 689977 689977
Grommet, Flexible, 1.06” (Not Shown) 632415 632415 632415 632415
34
TXV, with internal check valve (Not Shown) - - - - - - 664576 664576
TXV/Distributor with external check valve
assy. (Not Shown)
664556 664556 - - - - - -
35 PVC, Drain Tube, 3/4” (Not Shown) 656355 656355 656355 656355
36 PVC, Drain Plug, 3/4” (Not Shown) 656356 656356 656356 656356
37 Nut, Plastic-Knurl 3/4 FGH (Not Shown) 663656 663656 663656 663656
38 Filter,Permanent (Not Shown) 669654 669654 669654 669654
39 Drain Pan 669665 669665 669665 669665
40 Cap, Charging Port (Not Shown) - - - - - - 662102 662102
41 Core, Charging Port (Not Shown) 662103 662103 662103 662103
42
Distributor, 8 CIR, Part of Coil Assembly
Item 30 - 297192R (Not Shown)
- - - - - - 663586 663586
43 Fitting, Access (Not Shown) 663812 663812 - - - - - -
44 Cap, Service Port, Brass (Not Shown) 663818 663818 - - - - - -
45 Box, Electrical, Bottom/Sides 295881R 295881R 295881R 295881R
46 Cover, Electrical Box 295411R 295411R 295411R 295411R
47 Switch, Limit-Freezestat M0062206 M0062206 M0062206 M0062206
