P-ELEC, Page 9
Parts for Model EXUB (cont’d)
Explosion Resistant, Electric Unit Heaters
Item
No. Description
12” fan size 16” fan size 20” fan size
5 & 7.5 kW 10 kW 15 & 20 kW 25 & 30 kW
1 Core assembly ( with bus bars) Specify Voltage, phase, and kilowatts ( V-Ph-kW)
2 Bottom panel 235459 235477 235490
3 Left side panel 235460 235478 235491
4 Louver blades 235461 235479 235492
5 Top panel 235462 235480 235493
6 Right side panel 235463 235481 235494
7 Fan panel 235464 235482 235495
8 Fan blades
5.0 kW = 235451
7.5 kW = 235452 10.0 kW = 235453
15.0 kW = 235454
20.0 kW = 235455
25.0 kW = 235456
30.0 kW = 235457
9 Fan guard (2 pieces) 235465 235483 235496
10 Motor, explosion-proof
115/208-230V, 1Ø, 60Hz = 235446
208-230/460V, 3Ø, 60Hz = 235447
575V, 3Ø, 60Hz = 235449
208-230/460V, 3Ø, 60Hz = 235448
575V, 3Q, 60Hz = 235450
11 Right side motor bracket 235458
12 Motor base 235466 235484 235497
13 Left side motor bracket 235473
14 Expansion union, female 235474
15 Conduit, expansion union to elbow 235467 235485 235498
15A Reducing bushing 235475
16 Thermostat, ex-proof 234436, (CX1 ex-proof wall thermostat)
16A Elbow, 90° 235476
17 Conduit, potted
235468 with thermostat
235469 without thermostat
235500 with thermostat
235501 without thermostat
18 Conduit, vertical 235470 235486 235499
19 O-ring, element enclosure cover 235488
20 Cover, element enclosure 235489
21 Guard, element enclosure 235504
22 Conduit, motor box to enclosure 235471 235502
22A Union 235505
23 Box, motor outlet 235506
23A Conduit, motor to motor box 235472 235487 235503
24 Enclosure, control 235507
25 Contactor 120V = 235508, 24V = 235509
26 Transformer 120V = 235510, 24V = 235511
27 Bracket, Transformer ground 235512
28 Grounding lug 235513
29 Fuse 120V = 1/4 Amp (235514), 24V = 1 Amp (235515)
30 Printed circuit board assembly 120V = 235516, 24V = 235517
31 High limit, automatic reset 235518
32 Conductive cement, high limit 235519
33 Bracket, transformer 235520
34 O-ring, control enclosure cover 235521
35 Cover, control enclosure 235522
36 Plug, 3/4” NPT explosion-proof 235523
37 Nut, bus bar 235524
38 Bus bar, long straight 235525
39 Bus bar, short straight 235526
40 Bus bar, short curved 235527
41 Bus bar, long curved 235528
42 High limit, manual reset 235529
43 Handle, Disconnect 235530
44 Switch, Disconnect 60A Non-Fused 235531
