IN STAL LA TION
IN STRUC TION
INSTALLATION INSTRUCTIONS FOR
560201
SUPPLY AIR PLENUM AND GRILLE KIT
B5SM-090/120 SERIES AIR HANDLER
DOU BLE DE FLEC TION DIS CHARGE AIR GRILLE KIT - SKU# 560201 (48" x 19" - A
t
= 5.92 Ft.
2
)
Air Handler
Model No.
CFM
Range
Velocity
(FPM)
(1)
Noise
Criteria
(NC)
Pressure
Loss
(in. WC)
Deflection Setting
Feet (Meters) of Throw
@ Terminal Velocity Shown
150 FPM
100 FPM
50 FPM
B5SM-090*
2750
475
18
0.03
A
0
o
39 (11.9)
57 (17.4)
95 (16.8)
0.03
B
22 ½
o
31 (9.5)
46 (14.0)
76 (23.2)
0.04
C
45
o
20 (6.1)
29 (8.8)
48 (14.6)
3000
500
20
0.03
A
0
o
41 (12.5)
61 (18.6)
98 (29.9)
0.03
B
22 ½
o
33 (10.1)
49 (14.9)
78 ( 23.8)
0.05
C
45
o
21 (6.4)
31 (9.4)
49 (14.9)
3250
550
22
0.03
A
0
o
45 (13.7)
67 (20.4)
101 (30.8)
0.04
B
22 ½
o
36 (11.0)
54 (16.5)
80 (24.4)
0.06
C
45
o
22 (6.7)
34 (10.4)
50 (15.2)
B5SM-120
3750
625
26
0.04
A
0
o
51 (15.5)
76 (23.2)
107 (32.6)
0.05
B
22 ½
o
41 (12.5)
61 (18.6)
85 (25.9)
0.07
C
45
o
25 (7.6)
38 (11.6)
53 (16.2)
4000
675
28
0.05
A
0
o
55 ( 16.8)
81 (24.7)
113 (34.4)
0.05
B
22 ½
o
44 (13.4)
65 (19.8)
90 (27.4)
0.08
C
45
o
27 (8.2)
41 (12.5)
57 (17.4)
4250
725
30
0.06
A
0
o
59 (18.0)
85 (25.9)
118 (36)
0.06
B
22 ½
o
47 (14.3)
68 (20.7)
94 (28.7)
0.09
C
45
o
30 (9.1)
43 (13.1)
60 (18.3)
Notes:
(1)
Noise Criteria (NC) values based on a single register operating at 0
o
deflection. For deflections of 22 ½
o
and 45
o
, increase stated sound levels
by 1 and 7 NC
Air Pattern Obtained with Various
Deflection Settings
A DE FLEC TION - 0
O
B DE FLEC TION - 22 ½
O
C DE FLEC TION - 45
O
Recommended Noise Criteria (NC)
(1)
Communication Environment
Typical Occupancy
Below NC 25
Extremely quiet environment; suppressed
speech is quite audible; suitable for acute
pickup of all sounds.
Broadcasting studios, concert
halls, music rooms.
NC 30
Very quiet office; suitable for large
conferences; telephone use satisfactory.
Residences, theatres, libraries,
executive offices, directors
rooms.
NC 35
Quiet office; satisfactory for conference at a 15
ft. table; normal voice 10-30 ft.; telephone use
satisfactory.
Private offices, schools, hotel
rooms, courtrooms, churches,
hospitals rooms.
NC 40
Satisfactory for conference at a 6-8 ft. table;
normal voice 6-12 ft.; telephone use
satisfactory.
General office, labs, dining
rooms
NC 45
Satisfactory for conference at a 4-5 ft. table;
normal voice 3-6 ft.; raised voice 6-12 ft;
telephone use occasionally difficult.
Retail stores, cafeterias, lobby
areas, large drafting &
engineering offices, reception
areas.
Above NC 50
Unsatisfactory for conference of more than two
or three persons; normal voice 1-2 ft.; raised
voice 3-6 ft; telephone use slightly difficult.
Computer rooms, stenographic
pools, print machine rooms,
process areas.
Application
Recommended
Velometer Velocities
Broadcasting Studios
500 FPM
Residences, Apartments, Churches, Hotel Bedrooms
500 to 750 FPM
Legitimate Theatres, Private Offices - Acoustically Treated
500 to 1000 FPM
Motion Picture Theatres, Private Offices - not treated
1000 to 1250 FPM
General Offices
1250 to 1500 FPM
Stores, Upper Floors and Main Floors
1500 FPM
Industrial Buildings
1500 to 2000 FPM
Ve loc ity Lim i ta tions for Var i ous Ap pli ca tions
The sound caused by an air outlet in operation is directly proportional to the
velocity of the air passing through it. As air velocity increases, so does the
noise level.
The following recommended outlet velocities are within the safe sound
limits for most applications.
NEISG01
SUPERSEDES 03-03-10
MARCH 18, 2010
