Form I-UD&APD Series-HA (11-14), Page 1
APPLIES TO:
Standard Power Vent Unit Heaters:
Models UDAP, UDBP and ADP
Separated Combustion Unit Heaters:
Models UDAS and UDBS
FORM I-UD&APD Series-HA (11-14)
Obsoletes Installation Form RZ-NA- I-UD-HA
High Altitude Kits for Elevations above 6000Ft / 1830M
Options DJ20 & DJ21
Application
If a Standard Power Vent or Separated Combustion Unit Heater is being installed above 2,000 ft
(610 M), the input rate must be derated. This is done by adjusting the valve outlet pressure as
explained in the heater installation manual. In addition, if the heater is being installed at an altitude
above 6,000 ft (1,830 M), the pressure switch must be changed.
The high altitude pressure switch ordered as Option DJ20 or DJ21, High Altitude Kit, varies by
Model, Size and type of application. Option DJ20 or DJ21 is
REQUIRED above 6,000 ft (1,830 M)
Be sure your kit matches your installation.
Option DJ20
Installed as
a Std. Power
Vented Fan
Type Unit
Heater
Std Power Vent Unit
Heater
30
45
60
75
100
125
150
175
200
225
250
300
350
400
Pkg P/N
197117
197118
197117
201162
201163
High Altitude Switch P/N
197031
197032
197031
201160
201161
Negative Pressure
OFF Setpoint “w.c.”
0.35
0.45
0.35
1.00
1.30
Label Color
Purple
Pink
Purple
Brown
White
Option DJ21
Installed as
a Std. Power
Vented Fan
Type Unit
Heater with
Option AV6
for Common
Venting
Std Power Vent Unit
Heater w/ Opt AV6
30
45
60
75
100
Pkg P/N
197119 197118
197120
197121
High Altitude Switch P/N
197029 197032
196362
196388
Negative Pressure
OFF Setpoint “w.c.”
0.60
0.45
0.55
0.50
Label Color
Lt Blue
Pink
White
Orange
Option DJ20
Installed as
a Separated
Combustion
Fan Type Unit
Heater
Separated Combus-
tion Unit Heater
30
45
60
75
100
125
150 175
200
225
250 300
350
400
Pkg P/N
197119
197121 197205
197117
201162
201163
High Altitude Switch P/N
197029
196388 197030
197031
201160
201161
Negative Pressure
OFF Setpoint “w.c.”
0.60
0.50
0.40
0.35
1.00
1.30
Label Color
Lt Blue
Orange
Green
Purple
Brown
White
Option DJ20
Installed
as a Std.
Power Vented
Blower Type
Unit Heater
Std Power Vent Unit
Heater
30
45
60
75
100
125
150
175 200 225 250 300
350
400
Pkg P/N
197117
197118
197117
201162
201163
201162
High Altitude Switch P/N
197031
197032
197031
201160
201161
201160
Negative Pressure
OFF Setpoint “w.c.”
0.35
0.45
0.35
1.00
1.30
1.00
Label Color
Purple
Pink
Purple
Brown
White
Brown
Kit Components
Option DJ20
Installed as
a Separated
Combustion
Blower Type
Unit Heater
Separated Combus-
tion Unit Heater
30
45
60
75
100
125
150
175 200 225 250 300
350
400
Pkg P/N
197117 197118 202103 197118 197117 197205
197118
201162
201163
201162
High Altitude Switch P/N
197031 197032 196362 197203 197031 197030
197031
201160
201161
201160
Negative Pressure
OFF Setpoint “w.c.”
0.35
0.45
0.55
0.45
0.35
0.40
0.35
1.00
1.30
1.00
Label Color
Purple
Pink
White
Pink
Purple
Green
Purple
Brown
White
Brown
