DSMC DISPLAYS
A CAMERA CUSTOMIZED TO YOUR SHOOTING NEEDS
5" TOUCH LCD
Allows for complete control of camera navigation
and settings
Great for lightweight configurations
Touchscreen allows for intuitive menu navigation
Integrated hinge with multi-axis rotational capabilities
9" TOUCH LCD
Allows for complete control of camera navigation and
settings. Greater viewing window adds value to display
tools such as Magnify and Touch Focus
Resolution: 1280x784
Touchscreen allows for intuitive menu navigation
Integrated hinge with multi-axis rotational capabilities
BOMB EVF
®
(OLED)
Advanced OLED technology, providing truer blacks and more accurate color
Resolution: 1280x1024
Features integrated eyepiece heater and 2 user definable buttons
BOMB EVF ®
MOUNTED TO EPIC
DSMC POWER
A CAMERA CUSTOMIZED TO YOUR SHOOTING NEEDS
STANDARD REDVOLT BATTERY
Great for lightweight configurations
Power the camera with the DSMC Side Handle,
Pro Battery Module (Dual), or Pro Battery Module (Quad)
REDVOLTS provide over 30 minutes of power per charge
*Battery Modules Require a +1 Adaptor Module or Module Adaptor
REDVOLT XL BATTERY
60-90 Minutes of power per charge
Requires the Pro Battery Module (Quad) & REDVOLT
Charger (Quad)
Great for longer shoots
*Battery Modules Require a +1 Adaptor Module or Module Adaptor
RED BRICK ® BATTERIES
OPTIMAL FOR LONGER RECORD TIME
90-120 Minutes of power per charge
Connect to EPIC or SCARLET-X ® with the Backpack
Quickplate and DSMC Backpack, or DSMC Battery Belt Clip
Requires RED Charger
Great for longer shoots and large productions
REDVOLT
®
BATTERIES
SPECIFICALLY DESIGNED FOR DSMC
