Hub Caps/Wheel Covers
• The hub caps must be removed before raising the vehicle off the ground.
• For single rear-wheel (SRW) models, use the blade on the end of the lug wrench
to pry the hub cap off. Insert the blade end into the pry-off notch and carefully pop
off the hub cap with a back-and-forth motion.
• On models with dual rear wheels (DRW), you must first remove the hub caps. The
jack handle driver has a hook at one end that will fit in the pry off notch of the rear
hub caps. Position the hook and pull out on the ratchet firmly. The hub cap should
pop off. The wheel skins can now be removed. For the front hub cap use the blade
on the end of the lug wrench to pry the caps off. The wheel skin can now be
removed.
• You must use the flat end of the lug wrench to pry off the wheel skins. Insert the
flat tip completely and using a back-and-forth motion, loosen the wheel skin.
Repeat this procedure around the tire until the skin pops off.
• Replace the wheel skins first using a rubber mallet. When replacing the hub caps,
tilt the cap retainer over the lug nut bolt circle and strike the high side down with
a rubber mallet. Be sure that the hub caps and wheel skins are firmly seated
around the wheel.
Wheel Nuts
All wheel nuts should be tightened occasionally to eliminate the possibility of wheel studs
being sheared or the bolt holes in the wheels becoming elongated. This is especially
important during the first few hundred miles/kilometers of operation to allow the wheel
nuts to become properly set. All wheel nuts should first be firmly seated against the wheel.
The wheel nuts should then be tightened to recommended torque. Tighten the wheel nuts
to final torque in increments. Progress around the bolt circle, tightening the wheel nut
opposite to the wheel nut just previously tightened until final torque is achieved.
Recommended torques are shown in the following chart.
Disc Wheels
Nut Type Stud Size Hex Size Torque Ft Lbs Torque Newton
Meters
Cone M14 x 1.5 22 mm 120-150 160-200
Flanged M14 x 1.5 22 mm 130-160 190-220
