PS Engineering
PMA8000B-MP3 Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-890-0403 Rev. 4, Jan. 2011
Appendix B – PMA 8000B MP3 Installation Drawings
J2 J1
Viewed from Back
15
30
44 1
16
31
15
30
44 1
16
31
Ground Lug
Ground Lug
475-440-0001 (x2)
Back plate assy
475-009-0001
ground lug (x2)
475-440-0001 (x2)
Screw w/washer
Ground lug detail
Rear plate detail (not to scale)
0.37 in
3.87 in
5.53 in
6.04 in
0.36 in
0.96 in
1.28 in
6.31 in
1.28 in
Ca ut i on: Ap p l y st ea d y p r essu r e t o t h e bez el wh i l e scr ewi n g t h e u n i t i n t o t h e t r a y t o
en su r e even sea t i n g of t h e u n i t a n d con n ect or s.
