|ф|)|

SoiM) - U

sim

; Tin: Ai i)io/\

i d e o

мп

acks

((

’

)

( (Ull’OM N I \ iUl.O IM4 I s

mponent Video inputs pro-

'vick for the highest possible

color aña picture resolution in the

playback of digital simal source

material, such as with DVD play
ers. The color difference signals

(Pb, Pr) and the luminance (Y)

signal are connected and received
separately, which allows for
improvea color bandwidth infor
mation (not possible when using
comjMsite video or S-Video con
nections).

Ф.

ÍBEOIW1

Connect the Component (Y,

Pb, Pr) Video OUT j^ks from
the DVD player (or similar
device) to the (Y, Pb, Pr) in(put)

jacks on the TV.

Connect the red and white

AUDIO CABLES to the Axidio

(left and right) output jacks on the
rear of the accessoiy oevice to the
Audio (L and R) AV1 in(put) jacks
on the TV.

<|> 'Dim the TV and the DVD

f (or digital accessory device)

I ON.

Press the M. MEDIA button

on the remote control until the

CVI source is selected. After CVI
mmears, insert a disc into ftie
DVD (or oftier digital accessory
device) and press Are PLAY but
ton to view the disc on the televi
sion, If CVI did not appear, per
form steps 5-9.

NOTE: The actions described in

steps 5-9 are not illustrated on this

If CVI did not appear

onscreen as one of the choices

available to you by pressing the
M. MEDIA button, press the M
Link button on the remote con
trol to display the M-Link’"
onscreen menu.

Press the CURSOR RING

RIGHT or CURSOR RING

I LEFT to highlight AVI.

Press the CURSOR RING

I UP to toggle from AVI to CVI.

<|> Press the STATUS/EXITbut-

ton to remove the M-Link™ menu

I from the screen.

Press the M. MEDIA button

I to tune to the CVI source. You

are now ready to view the disc on

the TV. ^

—I

NOTE; RqfHXitciUy pressing the M. MEDIA
button on ilw remote will toggle the picture
source from the current chsnncl, the lest viewed
channel, then the CVI (or AVI ) connection, the
AV2 connection, and die AV3 connection. l).sc
CVI for Component Video Connections.

BACK OF TV

«MW

----- NEtIN.'

о / Т Л о

BACK OF DIGITAL

ACCESSORY

DBS, DVD, Video Game, etc.

{EQUIPFED WITH COMPONENT VIDEO

OUTPUTS AND AUDIO OUTPUT JACKS)

NOTE: Optional video/audio cables (with
standard RCA plug connectors) are available
to complete your component video input jack
connections. Contact your dealer or our Parts
Information Center (l-SOO-SS I-8SS5) to order
any optional accessories.

. S M A K I 1 1 1 1 1 ’

The description for the

component video connectors

may differ depending on the DVD

player or accessory digital source
equipment used (for example, Y,
Pb, Pr; Y, B-Y, R-Y; Y, Cr, Cb).

Although abbreviations and terms

may vary, the letters

and

stand

for the blue and red color compo

nent signal connectors, and

indi

cates ftie luminance signal. Refer
to your DVD or digital accessory
owner’s manual for definitions and

connection details.
