SoundMax SM-CDM1038 - Manual (Page 25)

24
Specification
General
Power supply
12 V DC
Current consumption max. 10
Maximum power output 50Wx4 channels
Fuse 1A & 10A
Dimensions (L x W x H) 162 x 178 x 50 mm
Temperature range -20 0 - +60 0
Installation angle 0 0 – +/-30 0
FM stereo radio
Frequency range
87.5 - 108.0 MHz
Presettable stations 18
Usable sensitivity 8 dB
MW (AM) radio
Frequency range
522 kHz-1620 kHz
Presettable stations 12
Usable sensitivity 30 dB
Disc player
System
Compact disc audio system
Format support CDDA/MP3/WMA
Discs support D/CD-R/CD-RW
Signal to noise CD >80 dB
Electronic shock protection 45 sec. ESP for CD, 120 sec. for MP3
Line out
Output
2 channel RCA line-out (2V)
Specifications are subject to change without notice. Dimensions are approximate.
