A ttaching the S ide S peaker B affles
r Locate and align the
S peaker B aeei . ics
y bur new Projection
Television comes with it’s
Side Speaker Baffles detached.
Locate the Speaker Baffles and
unwrap them. To attach the
Speaker Baffles to the TV cabi­
net, follow the steps to the right.
This Projection Television
comes with two Side Speaker
Baffles (right and left) that the
consumer must attach.
mounting holes in each side
of the PTV cabinet and the
mounting pins on the inside
of the Speaker Baffles (six
each side).
f
Press the baffle to the cabinet. Then with your fist give a gentle
but firm hit to the Speaker Baffle (directly over the areas of the mount­
ing pins). You will hear the baffle snap into place. If you notice any
space between the baffle and the PTV cabinet, the mounting pins did
not set properly into the mounting holes. Please repeat the process.
Mounting Holes in side
of PTV cabinet
Mounting Pins inside of
j Speaker Baftle
Ai roM vnc S
jrprst Time Setup automatical-
J l ly takes care of some basic
TV control settings for you.
Follow the steps in this section
to quickly add area channel
numbers into the TV's memory,
and set the TV for your connect­
ed signal (Antenna or Cable.)
You can also set-up your TV
Guide Plus+ feature for the first
time as well.
Please check that your
other antenna or cable is
connected to the plug
marked ANT B on
the TV rear input panel.
Press STATUS to Quit
or
Press "M" to Continue
Please thoroughly read
the section in your
owners manual which
details the proper setup
and operation of the
Surround-Sound System.
Press 'M' to Continue
AiS)-------------------
r Press the MENU (M)
button on the remote or TV.
An on-screen list of TV fea­
tures shows on the screen -
"MAIN MENU".
¿
Select "1ST TIME
SETUP" on the TV's Main
Menu. (Selected MENU item
is highlighted in RED.)
Press the remote's Menu
buttons to move UP/DOWN
and from SIDE-TO-SIDE
within the list of on-screen
features.
Press ADV(ance) A T and
( + ) (-) on the TV to move
UP/DOWN and from SIDE-
TO-SIDE within the list of
on-screen features.
Press MENU (M) but­
ton on the remote or TV to
begin SETUP.
Follow the instructions
shown on the TV screen to
guide you through the First
Time Setup and use of your
new TV.
This TV is equipped with
Press "AT" to select the the TV Guide Plus+ feature.
The Fiгs^Time Setup Many of the current TV language you would like
provides a simple method control settings will be the TV displays to use. This feature is designed
of adjusting the most ^ modified by continuing
► I ENGLISH I
to operate only on the
important controls for ^ with First-Time Setup. main antenna, ANT A,
this television receiver.
Press STATUS to Quit
ESPAÑOL
FRANÇAIS
Press ‘M’ To Continue or
Press “M" to Continue Press "M" to Continue Press "M" to Continue
Please check that your
main antenna or cable is
connected to the plug
marked ANT A on
the TV rear input panel
Press STATUS to Quit
or
Press "M" to Continue
* Please Wait *
System is testing for
correct tuning mode
for ANT A.
1
* Please Wait *
System is searching for
all active channels
on ANT A.
Testing channel 2
in cable mode.
The search for active
channels is complete
for ANT A.
17 channels were found
and saved in memory
Press "M" to Continue
• Please Wait *
System is testing for
correct tuning mode
for ANT B.
1
* Please Wait *
System is searching for
all active channels
on ANT B.
Testing channel 2
in cable mode.
The search for active
channels is complete
fpr ANT B.
17 channels were found
and saved in memory
Press "M" to Continue
This TV is equipped with
a Surround-Sound system.
Surround Sound requires
the use of additional
speakers being placed
around your room.
Press "M" to Continue
If there is
fringe on the
use this ad
improve t
I
ÎED or BLUE
WHITE cross,
ustment to
le picture.
n
Press ’M"
-1
Press
to Continue
)r -
to Return
ISE REFER
I YOUR
TV GUIDE PLUS + "I
INSTRUCTION MANUAL
for DEfiliiLS ON
1st TIME SETUP.
After ALL connections
and First'Time Setup
for TV GUIDE PLUS
" are completed, the TV '
will have to be turned
OFF overnight to receive
program information.
This completes the
First-Time Setup.
Press "M" to Exit Setup
S mart H elp
_• Press the STATUS button on
-V the remote or TV to stop the
j SETUP at any time.
• Remember, SETUP is a first -use, one­
time operation and will not have to be
repeated (only the clock settings can be
lost).
• Even if there is no Antenna or Cable
signal connected to the ANT(enna) B
input (located on the rear of the TV), 1st
Time Setup will still attempt to add
channels into memory for that source.
In such cases, a channel search in the
Antenna Mode will be completed, and
“0 channels saved in memory” will be
displayed on-screen.
2 - EL6246 E001
