Kvika, Tent 8’ x 8, Before you begin

background image

3. Assemble remaining interlock-

ing shock-corded gray pole.

4. Fold back vestibule on front of

tent to locate sleeve on under
side of rainfly. (Fig. 9)

5. Slide gray pole through sleeve

in rainfly. (Fig. 9)

STITCH LINE

KVIKA

TM

TENT 8’ X 8’

MODEL 2000001059

Before you begin

Read all instructions before set up.
• Select a level campsite clear of rocks, branches, and other hard

or sharp objects, to install your tent.

WARNING: Keep clear of overhead power lines.

• Do not set up your tent under trees.
• For best results in windy conditions, position end of tent into

the wind.

• Enlist the help of at least one other person to assist you when

it is time to assemble the tent.

Fig. 2

Fig. 3

To Set Up Tent

1. Unfold tent and spread out on a clean, level surface with the

door facing the desired direction. Unzip door. (Fig. 1)

4. Insert one end of each black pole into

pins in front corners oftent. (Fig. 3)

5. Go to opposite end of each pole and gradually apply pressure

to the pole forming an arch. Insert the pin into the pole end
at the tent corners.
(Fig. 4)

6. Stretch corners of

tent until floor is taut
then hammer stakes
through loops to
secure.

Fig. 4

Parts and Components

Description

Part Number

Main Poles, Black (2)

5010000360

Side Poles, Gray (2)

5010000361

Rainfly

5010000362

7. Attach frame clips along edges

of tent to black main poles
(Fig. 5)

8. Assemble first interlocking

shock-corded, gray pole.

Fig. 5

9. Slide the gray pole through sleeve on front of tent. (Fig. 6)

Fig. 7

Fig. 6

10. Pull down on pole and insert into

center pin location on side of tent.
(Fig. 7)

11. Go to opposite side of tent and

gradually apply pressure to the
pole to form an arch. Insert the
pin into the pole, then drive stake
through metal ring to secure.

12. Attach frame clips on both sides

of tent to gray pole.

To Attach Rainfly

1. Drape rainfly over tent with vestibule centered over the door

on the front of tent (Fig 8).
NOTE: Hook and loop
fasteners, located on
seams of underside
of rainfly, should be
centered over black
and gray poles.

Fig. 10

Fig. 9

To Set Up Tent

(continued)

(continued on other side)

2. Assemble main tent poles by interlocking both longer, black

shock-corded, poles.

3. Insert black poles through sleeves, with the black seams, in

top of tent forming an “X” as shown. (Fig. 2)

Fig. 1

Door

Sleeves with
black seams

Fig. 8

Vestibule

on Rainfly

Front on Tent

Sleeve

in Rainfly

2. Secure rainfly with velcro hook

& loop fasteners, on underside
of rainfly, around black poles at
the back of tent and gray pole
on both sides. (Fig. 9)
