Coleman 5998-830 - Manual

WARNINGS:
• Never leave pump unattended while in use.
• Carefully inspect the pump for damage before use and every use
thereafter. Do not use if found damaged.
• Do not change the pump plug in any way.
• Do not leave unit plugged into 110 Volt AC power source
while unattended.
• Keep pump out of reach of children.
• Do not use in or around water. For indoor use only.
• Never look into or point any opening toward your eyes while pump
is operating.
• Do not open pump case, electrical hazards may result. There are no
serviceable parts.
• For optimum pump performance, do not operate pump for more than
10 minutes continuously. Allow pump to cool down
between operations.
• Let pump cool before storing with bed. Never twist the cord.
• Do not attempt to put any objects into the inflation or deflation ports
at any time.
• Never allow paper, debris or small articles to be sucked into pump
while operating.
• Do not let your bed come in contact with sharp,
pointed objects.
• Do not use or place near heaters, open flame or other hot objects.
• Do not store in extreme temperatures that are above 90°F(32°C) or
below 50°F(10°C).
• Product must be at room temperature prior to inflating.
NOTE: The Coleman ® Deluxe pump is equipped with an automatic
reset thermostat. The thermostat will automatically turn the pump off if
the motor gets too hot. If you pump turns off, place the hand control
switch in the OFF position, unplug and allow the pump to cool down.
The pump will resume normal operation once it has cooled.
GROUNDED
OUTLET
GROUNDING
PIN
(A)
GROUNDED
OUTLET BOX
(B) (C)
ADAPTER
TAB FOR
GROUNDING SCREW
METAL
SCREW
GROUNDING INSTRUCTIONS
This pump should be grounded while in use to protect the operator
from electric shock. The pump is equipped with a 3-conductor cord
and 3-prong grounding type plug to fit the proper grounding type
receptacle. This pump is for use on any standard 110 Volt AC
electrical outlet, and has a plug that looks like that shown in sketch
(A). An adapter, see sketches (B & C), is available for connecting
3-prong grounding type plugs, see sketch (A), to 2-prong receptacles.
The green colored rigid tab, see sketch (C ), extending from the
adapter must be connected to a permanent ground, such as a
properly grounded outlet box. (Follow the adapter installation
instructions provided with the adapter).
EXTENSION CORDS
Make sure your extension cord is in good condition. When using an
extension cord, be sure to use one heavy enough to carry the current
your product will draw. An undersized cord will cause a drop in the line
voltage resulting in loss of power and overheating. The following table
shows the correct size to use depending on cord length and
nameplate ampere rating. If in doubt, use the next heavier gage. The
smaller the gage number, the heavier the extension cord.
Please call or write us with any comments or questions
The Coleman Company, Inc.
3600 N. Hydraulic
Wichita, KS 67219 U.S.A.
1-800-835-3278
TDD: 316-832-8707
Manufactured in China
How to Use and Enjoy Your
Coleman ® Sleep System
US C
Warning: the power cord on this product contains lead, a chemical
known to the State of California to cause cancer, birth defects or
other reproductive harm. Wash hands after handling.
Model #s 5998-830 and 5998-835
Volts
110 AC
Ampere rating
More Than - Not More Than
0 - 5
5 - 10
10 - 12
12 - 16
Total length of cord in feet
0-25’ 26’-50’ 51’-100’ 101’-150’
AWG
18 16 16 14
18 16 14 12
16 16 14 12
14 12 Not recommended
The Coleman Company, Inc. has been
making people comfortable in the
great outdoors since 1901. We’ve lit
your way, cooked your food and
warmed your nights. Our products
have helped make a million memories.
People from all over the world have
counted on Coleman time and again
for innovation and dependability.
That’s why, after almost a century, our
dedication to quality shines on.
(8/3/05)
© 2005 The Coleman Company, Inc. All Rights reserved.
Coleman
® , Quickbed ® and are registered
trademarks and Double-Lock™ and Comfort Control™ are
trademarks of The Coleman Company, Inc.
