Compaq iPAQ - Manual (Page 25)

Adding System Memory and Upgrading the Internal Hard Drive
3-2 Quick Setup & User’s Guide
Using the Torx screwdriver 4 (provided), remove the tamper-proof Torx
screw 3 and pull the security bar 1 away from the personal computer.
Uninstalling the iPAQ Desktop Security Bar
Removing and Replacing the Side Access
Panels
To access system memory or the internal hard drive, you must remove the side
access panel as shown below:
1. Exit all software applications, shut down the operating system software,
turn off the Personal Computer and any external devices, then disconnect
the power cord from the power outlet.
2. Uninstall the iPAQ Desktop Security Bar, if installed. Refer to
“Uninstalling the iPAQ Desktop Security Bar” on page 3-1.
QuickSetup_UsersGuide.book Page 2 Wednesday, May 30, 2001 9:36 AM
