Page 4
4
NV360/580 Series
20003565
Fireplace Dimensions
Fig. 1 Fireplace specifications and framing dimensions.
A
S
3565a
NV360
Specs
12/6/00 djt
K
J
CL
T - Rough Opening Width
R
D
G
C
Rough
Opening
Height
Electrical Access
Rough
Opening
Depth
Recessed
Nailing Flange
Gas Line
Access
M
Outside Air
�
�
�
�
�
�
�
�
G
F
E
Q
P
N
O
L
B
Ref.
NV360
NV580
A
41"
(1046 mm)
47"
(1194 mm)
B
37¹⁄₂"
(953 mm)
41¹⁄₄"
(1048 mm)
C
36"
(914 mm)
42"
(1067 mm)
D
24¹⁄₂"
(622 mm)
28¹⁄₂"
(724 mm)
E
7"
(179 mm)
7"
(179 mm)
F
6"
(152 mm)
6"
(152 mm)
G
1¹⁄₄"
(32 mm)
1¹⁄₄"
(32 mm)
H
19¹⁄₄"
(489 mm)
23¹⁄₂"
(591 mm)
I
5¹⁄₂"
(140 mm)
5¹⁄₂"
(140 mm)
J
25¹⁄₄"
(641 mm)
31¹⁄₄"
(794 mm)
K
5/8"
(16 mm)
5/8"
(16 mm)
L
9¹⁄₄"
(235 mm)
9¹⁄₄"
(235 mm)
M
5¹⁄₂"
(140 mm)
5¹⁄₂"
(140 mm)
N
3"
(76 mm)
3"
(76 mm)
O
15¹⁄₄"
(387 mm)
15¹⁄₄"
(387 mm)
P
8"
(203 mm)
6³⁄₄"
(172 mm)
Q
2¹⁄₈"
(54 mm)
1¹⁄₈"
(29 mm)
R
6"
(152 mm) Dia.
8"
(203 mm) Dia.
Framing Dimensions
S
38¹⁄₂"
(978 mm)
42¹⁄₂"
(1080 mm)
T
41"
(1041 mm)
47¹⁄₄"
(1200 mm)
U
19¹⁄₄"
(489 mm)
23¹⁄₂"
(591 mm)
V
62¹⁄₄"
(1581 mm)
75"
(1905 mm)
W
44"
(1118 mm)
53"
(1346 mm)
X
31³⁄₄"
(807 mm)
38"
(965 mm)
