Vermont Casting NV580 - Manual (Page 14)

14
NV360/580 Series
20003565
24 VAC HOT
24 VAC RTN
"ON/OFF"
SWITCH
NOVA SIT 822 VALVE
HONEYWELL S8600 B IGNITION MODULE
120 VAC RTN
40VA
TRANSFORMER
120 VAC HOT
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
BLACK
FP670
NOVA SIT 822 VALVE WIRING DGRM.
(w/ Honeywell S8600 B Ignition Module)
4/30/98
PILOT
H
I L
O
HI
L O
E A
P
ILO T
1 5
3 4
GREEN
MV MVPV PV GND
(BURNER)
24V
GND 24V SENSE SPARK
FP670
Fig. 19 Vent Safety Switch wiring, EN/EP units.
TH
TP
TH
TP
Gas
Valve
FP1161
Vent Safety Switch
Wiring
11/2/01 djt
Thermopile
"ON/OFF"
Switch
Vent Safety
Switch
FP1161
Fig. 20 RN/RP units using a remote ON/OFF switch.
