Char-Broil 463210511 User Manual
Page 19
Grease Tray
Tank Retainer,Wire Form
Attach tank heat shield to cart back brace with #10-24x1/2" screws.
Place grease tray to the cart assembly as shown.
Insert tank retainer to the holes from the bottom shelf. Attach with a hitch pin.
5
6
Qty: 3
#10-24x1/2"
Machine Screw
Tank Heat Shield
19
Stand cart upright.
