background image

4-11

Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE Administration Guide for Cisco Unified CallManager

OL-11528-01

Chapter 4 Configuring Settings on the Cisco Unified IP Phone

Network Configuration Menu

DNS Server 1

DNS Server 2

DNS Server 3

DNS Server 4

DNS Server 5

Primary Domain Name System
(DNS) server (DNS Server 1) and
optional backup DNS servers (DNS
Server 2–5) used by the phone.

1.

Unlock network configuration options.

2.

Set the DHCP Enabled option to No.

3.

Scroll to the appropriate DNS Server
option, press the Edit softkey, and then
enter a new DNS server IP address.

4.

Press the Validate softkey.

5.

Repeat Steps 3 and 4 as needed to
assign backup DNS servers.

6.

Press the Save softkey.

Operational
VLAN ID

Auxiliary Virtual Local Area
Network (VLAN) configured on a
Cisco Catalyst switch in which the
phone is a member.

If the phone has not received an
auxiliary VLAN, this option
indicates the Administrative VLAN.

If neither the auxiliary VLAN nor the
Administrative VLAN are
configured, this option is blank.

The phone obtains its Operational VLAN
ID via Cisco Discovery Protocol (CDP)
from the switch to which the phone is
attached. To assign a VLAN ID manually,
use the Admin VLAN ID option.

Admin. VLAN
ID

Auxiliary VLAN in which the phone
is a member.

Used only if the phone does not
receive an auxiliary VLAN from the
switch, ignored otherwise.

1.

Unlock network configuration options.

2.

Scroll to the Admin. VLAN ID option,
press the Edit softkey, and then enter a
new Admin VLAN setting.

3.

Press the Validate softkey and then
press the Save softkey.

DHCP Enabled

Indicates whether DHCP is being
used by the phone.

1.

Unlock network configuration options.

2.

Scroll to the DHCP Enabled option and
press the No softkey to disable DHCP,
or press the Yes softkey to enable
DHCP.

3.

Press the Save softkey.

Table 4-2

Network Configuration Menu Options (continued)

Option

Description

To Change
