OmniSistem PR Star Brite - Manual (Page 2)

2/16
INDEX
SAFE USAGE OF THE PRODUCT 3
INSTALLING THE PRODUCT 4
POWER SUPPLY – MAINS 4
CONTROL CONNECTIONS 4
DMX TERMINATOR 6
SETUP OPTIONS-PRODUCT CONFIGURATION 6
OPERATION MENU 7
TO SET THE DMX START ADDRESS 8
DMX PROTOCOL 9
LED INDICATION 11
MAINTENANCE 11
TROUBLESHOOTING 11
TECHNICAL DATA 12
ELECTRICAL DIAGRAM 13
COMPONENT ORDER CODES 14
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without
notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the course of
product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence
arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
Power-cord 1 Pc
3-pin XLR cable 1 Pc With plug
5-pin signal connection cable 1 Pc With plug
This manual 1 Pc
