Configuring Input/Output Modules
The Series 1000 features true modularity--I/O channels operate completely independently
of each other. Using the following commands, each I/O channel in your dialer can be
configured to operate uniquely to satisfy your application requirements. For each I/O
channel, you may record a voice message, choose the format of spoken status reports,
program an alarm integration delay, alarm call out operation, and telephone number
calling sequence. Analog inputs also have user-selectable low and high alarm setpoints.
NOTE: Always verify the I/O channel TYPE before proceeding to configure any other
values for a channel. The dialer will reset a channel’s settings when this
channel’s TYPE is modified. If you are adding a new I/O channel to your
dialer, you must configure this channel’s TYPE first. Refer to Advanced Topics
for information on adding I/O modules to an existing configuration.
NOTE: Input modules come from the factory configured as STATUS only. At the very
least, you must configure your inputs to Call On Alarm (described below).
The following commands configure and report the current values for the channel level
operations of the Series 1000. They are in the order presented in the text. These settings
include:
Section Current
Setting
Change Setting Meaning
Channel Type
*c2 **c2nn
I/O Type of channel c
Alarm
Configuration
*c8 **c8n
Determines how channel c’s alarm operation
will be handled
Report Status
Flag
*c7 **c7n
Tells the dialer to report channel c’s status as
part of its answer message (n=0:Don’t, 1:Do)
Channel
Telephone List
*c41 **c41t*
List of telephone numbers that will be called to
report an alarm condition for channel c
Channel Status
*c0
Reads back the current status for channel c
Clear Channel
Counters
**c0 Clears the Counter, Runtime, Time In Alarm
values for the channel c
Channel Voice
Name
*c1 **c1~
Spoken name for channel c
Channel
Report Format
*c3 **c3nn
Selection of status information that is spoken
for channel c (*c0)
Channel
ON/OFF Delay
*c5 **c5nMMSS
Time that a physical state change will have to
occur for before channel c’s alarm state changes
Analog High
Setpoint
*c90 **c90aaa High setpoint for an analog input (in percent).
Used for analog alarm monitoring
Analog Low
Setpoint
*c91 **c91aaa Low setpoint for an analog input (in percent).
Used for analog alarm monitoring
