Scribe EC Quick Installation Guide
with Prism PLUS Printer
Document Revision: 2004/12/07
ScribeEC with OptiEC PRO printer
Installation Guide
Document Revision: 2004/12/28
POWER
CABLE
SERIAL
CABLE TO PC
FIREWIRE
CABLE TO PC
(IEEE-1394)
POWER
CABLES
PRINTER INTERFACE
CABLE BETWEEN A
LOADER AND A PRINTER
USB CABLE
TO PC
Making the Connection
1 & 2 Drive Systems have one firewire B cable connection (IEEE-1934B).
4 Drive Systems have two firewire B cable connections (IEEE-1934B).
PC Connection
Power cable
Serial cable
to a loader
USB cable
to a printer
*Firewire cable
to a drive bay
For additional information
on the firewire connection
refer to Appendix A
Note:
