Scribe EC Quick Installation Guide
with Prism PLUS Printer
Document Revision: 2004/12/07
ScribeEC with Prism PLUS printer
Installation Guide
Document Revision: 2004/12/28
Power cable
Printer cable
Serial cable
to the printer
Serial cable to the
ScribeEC loader
* Firewire cables
to the drive bay
Making the Connection
* 1 & 2 Drive Systems require one firewire cable connection (IEEE-1934).
* 4 Drive Systems require two firewire cable connections (IEEE-1934).
PC Connection
1 & 2 Drive Systems 4 Drive Systems
For additional information
on the firewire connection
refer to Appendix A
Note:
