78M6613 Evaluation Board User Manual
Rev. 2
17
Item Qty
Reference
Part
Footprint
Digi-Key
(MS : Mouser)
Part Number
Manufacture
ROHS
19
5 TP2,TP8,TP9,TP10,TP11
TP/1
SIP100P1
S1011E-36-ND
PBC36SAAN
Sullins Connector
Solutions
x
20
2
R2,R21
0
0603
P0.0GCT-ND
ERJ-3GEY0R00V
Panasonic - ECG
x
21
4
R3,R5,R13,R14
1K
0603
P1.00KHCT-ND
ERJ-3EKF1001V
Panasonic - ECG
x
22
3
R4,R6,R19
330
0603
P330GCT-ND
ERJ-3GEYJ331V
Panasonic - ECG
x
23
2
R7,R9
68
0603
P68GCT-ND
ERJ-3GEYJ680V
Panasonic - ECG
x
24
4
R8,R17,R29,R30
10K
0603
311-10KGRCT-ND
RC0603JR-0710KL
Yageo
x
25
2
R10,R25
0.004 1%
2.5W
2512
MS 66-ULR25R004FLFTR
ULR25R004FLFTR
IRC
x
26
3
R11,R12,R24
750
0603
P750GCT-ND
ERJ-3GEYJ751V
Panasonic - ECG
x
27
4
R15,R16,R26,R27
1M 0.1%
1206
MS 660-
RN732BTTD1004B25
RN732BTTD1004B25
KOA Speer
x
28
1
R18
750 0.1%
0603
P750YCT-ND
ERA-3YEB751V
Panasonic - ECG
x
29
2
R1,R20,R22
DNP
0603
–
–
–
–
30
1
R23
120
0805
P120CCT-ND
ERJ-6ENF1200V
Panasonic - ECG
x
31
1
R28
470
0603
P470GCT-ND
ERJ-3GEYJ471V
Panasonic - ECG
x
32
1
TP1
Wh
SIP100P2
S1011E-36-ND
PBC36SAAN
Sullins Connector
Solutions
x
33
1
TP4
CON7
SIP100P7
S1011E-36-ND
PBC36SAAN
Sullins Connector
Solutions
x
34
4
U1,U2,U3,U4
PS9122
SOIC6
DNP
–
–
–
35
1
U5
78M6613-32
QFN32
–
78M6613-IM
Maxim
x
36
1
U6
28-LD
SSOP
28-SSOP
768-1007-1-ND
FT232RL-REEL
FTDI
x
37
2
U7,U8
ADUM3201
8-SOIC
ADUM3201ARZ-ND
ADUM3201ARZ
Analog Devices
x
38
1
U9
RESET
CIRC
SOT-23-3
MAX810SEUR+TCT-ND
MAX810SEUR+T
Maxim
x
39
1
U10
RS485
10-WFDFN MAX13430EETB+TCT-ND
MAX13430EETB+T
Maxim
x
40
1
VR1
MAX8881
SOT23-6
MAX8881EUT33+T-ND
MAX8881EUT33+T
Maxim
x
41
1
VR2
VBT1-5V
8-SMD
102-1397-2-ND
VBT1-S5-S5-SMT
CUI Inc.
x
42
1
Y1
32.768KHz
4-SOJ
535-9166-1-ND
ABS25-32.768KHZ-T
Abracon
Corporation
x
