UM_6613_045 78M6613 Evaluation Board User Manual
Rev. 2 11
2.4 Verify Serial Connection to the PC
After connecting the USB cable from the 78M6613 Evaluation Board to the host PC, start the
HyperTerminal application (or another suitable communication program) and create a session using the
communication parameters shown in Table 1.
Table 1: COM Port Setup Parameters
Setup Parameter Value
Port speed (baud) 38400
Data bits 8
Parity None
Stop bits 1
Flow control None
HyperTerminal can be found in Windows by selecting Start All Programs Accessories 
Communications HyperTerminal. The connection parameters are configured by selecting File 
Properties. The New Connection Properties menu appears.
Select the appropriate COM port and click Configure. The COMn Properties menu appears.
Select
COM Port
