UG_8430_008

78Q8430 Linux Driver ARM Platform User Guide

Rev. 1.0

11

L: WOL

Syntax:

8430-tool ethn -L onnow [on|off|set data1 data2 data3 mask]
magic
[on|off|set MAC_addr ]

pmectl

[on|off]

pmepwr [on|off]

Description:

This command option causes the driver to configure and activate or deactivate the OnNow and Magic
Packet WOL features.

Operands:

onnow [on|off]

Keyword to configure and activate OnNow WOL. Toggles OnNow on or off.

set

Establishes the OnNow 6 byte key from the three 32-bit input data words, data1,
data2 and data3. The key is selected from the 12 bytes of the three input data
words based on the 12 least significant bits of the specified mask value. The
command enters interactive mode for the input of data2, data3 and mask. Each of
the operands, 3 data and 1 mask must be specified as 32-bit hex numbers, of the
form 0xnnnnnnnn.

magic [on|off]

Keyword to configure and activate Magic Packet WOL. Toggles Magic Packet on
or off.

set MAC_addr

Establishes the MAC address to be used for WOL recognition.

pmectl [on|off]

This keyword enables and disables the processor Power Management facility.

pmepwr [on|off] This keyword enables and disables processor low power mode. The on

value sets the processor into low power mode. The processor is then

able to be awakened by one of the two 8430 WOL methods.

Processor low power mode does not affect the power mode of the

8430.

m: RMON counter query

Syntax:

8430-tool ethn –m


Description:

This command option causes the driver to display all RMON counter values.

Operands:

None.
