RENEWAL PARTS IDENTIFICATION
Watts Element Bushing
Model per Element Reflector Terminal Insulation Support Retaining
Number Volts Element Model Number Sheet Cover Bushing Clip Clip
120 RTU-2083A-120V (2)
RADD-2164
208
800
RTU-2083AV-208V (2)
234-013411-011 306-014405-001 (2) ————————– ————————– ————————–
240 RTU-2083A-240V (2)
275 RTU-2083AV-275V (2)
120 RTU-3113A-120V (2)
RADD-3224
208
1100
RTU-3113AV-208V (2)
234-013411-012 306-014405-001 (2) ————————– ————————– ————————–
240 RTU-3113A-240V (2)
275 RTU-3113AV-275V (2)
208 RTU-3133AV-208V (2) 234-013411-013
RADD-3264
240
1300
RTU-3133A-240V (2) 234-013411-013
306-014405-001 (2) ————————– ————————– ————————–
275 RTU-3133AV-275V (2) 234-013411-013
480 RTU-3133A-480V (2) 234-013411-013
208 RTU-4183AV-208V (2)
RADD-4364
240
1800
RTU-4183A-240V (2)
234-013411-014 306-014405-001 (2) 032-013454-001 (4) 059-014304-002 059-017175-001
275 RTU-4183AV-275V (2)
480 RTU-4183A-480V (2)
208 RTU-5213AV-208V (2) 234-013411-015 032-013454-001 (8) 059-014304-002 (2) 059-017175-001 (2)
RADD-5434
240
2150
RTU-5213A-240V (2) 234-013411-015
306-014405-001 (2)
032-013454-001 (8) 059-014304-002 (2) 059-017175-001 (2)
275 RTU-5213AV-275V (2) 234-013411-015 032-013454-001 (8) 059-014304-002 (2) 059-017175-001 (2)
480 RTU-5213A-480V (2) 234-013411-015 032-013454-001 (8) 059-014304-002 (2) 059-017175-001 (2)
208 RTU-5253AV-208V (2)
RADD-5504
240
2500
RTU-5253A-240V (2)
234-013411-016 306-014405-001 (2) 032-013454-001 (12) 059-014304-002 (3) 059-017175-001 (3)
275 RTU-5253AV-275V (2)
480 RTU-5253A-480V (2)
208 RTU-6273AV-208V (2) 234-013411-017 032-013454-001 (12) 059-014304-002 (3) 059-017175-001 (3)
RADD-6544
240
2700
RTU-6273A-240V (2) 234-013411-017
306-014405-001 (2)
032-013454-001 (12) 059-014304-002 (3) 059-017175-001 (3)
275 RTU-6273AV-275V (2) 234-013411-017 032-013454-001 (12) 059-014304-002 (3) 059-017175-001 (3)
480 RTU-6273A-480V (2) 234-013411-017 032-013454-001 (12) 059-014304-002 (3) 059-017175-001 (3)
208 RTU-6303AV-208V (2)
RADD-6604
240
3000
RTU-6303A-240V (2)
234-013411-018 306-014405-001 (2) 032-013454-001 (16) 059-014304-002 (4) 059-017175-001 (4)
275 RTU-6303AV-275V (2)
480 RTU-6303A-480V (2)
208 RTU-7333AV-208V (2)
234-013411-006*
032-013454-001 (16) 059-014304-002 (4) 059-017175-001 (4)
RADD-7674
240
3350
RTU-7333A-240V (2)
and 306-014405-001 (2)
032-013454-001 (16) 059-014304-002 (4) 059-017175-001 (4)
275 RTU-7333AV-275V (2)
234-013411-015*
032-013454-001 (16) 059-014304-002 (4) 059-017175-001 (4)
480 RTU-7333A-480V (2) 032-013454-001 (16) 059-014304-002 (4) 059-017175-001 (4)
208 RTU-7363AV-208V (2)
234-013411-004*
RADD-7724
240
3600
RTU-7363A-240V (2)
and 306-014405-001 (2) 032-013454-001 (20) 059-014304-002 (5) 059-017175-001 (5)
275 RTU-7363AV-275V (2)
234-013411-012*
480 RTU-7363A-480V (2)
208 RTU-8453AV-208V (2) 234-013411-049 (2) 032-013454-001 (20) 059-014304-002 (5) 059-017175-001 (5)
RADD-8904
240
4500
RTU-8453A-240V (2) 234-013411-049 (2)
306-014405-001 (2)
032-013454-001 (20) 059-014304-002 (5) 059-017175-001 (5)
275 RTU-8453AV-275V (2) 234-013411-049 (2) 032-013454-001 (20) 059-014304-002 (5) 059-017175-001 (5)
480 RTU-8453A-480V (2) 234-013411-049 (2) 032-013454-001 (20) 059-014304-002 (5) 059-017175-001 (5)
RADD-7604X10 240 4000 RTU-7303AX10-240V (2) 234-013411-016 (2) 306-014405-001 (2) 023-013454-001 (24) 059-014304-002 (8) 059-017175-001 (6)
RADD-7604X13 240 or 480 5000 RTU-7303AX13-240 (2)** 243-013411-058 (3) 306-014405-002 (2) 032-013454-001 (23) 059-014304-002 (8) 059-017175-001 (9)
RADD-7604X9A 240 or 480 5500 RTU-7303AX9A-240 (2)** 234-013411-057 (4) 306-036916-003 (2) 032-013454-001 (32) 059-014304-002 (8) 059-017175-001 (10)
RADD-7724X38 240 or 480 6500 RTU-7363AX38-240 (2)** 234-013411-059 (4) 306-036916-003 (2) 032-013454-001 (32) 059-014304-002 (8) 059-017175-001 (11)
6 7 15 3 2 1
*For ease of installation, these reflectors shipped in two pieces (one each of part numbers listed).
**Shipped as 480V. Convert to 240V by changing jumpers. See WIRING Section on page 2.
NOTES:
1. Part numbers suffixed by a number in ( ) indicates the quantity of the same part number used.
2. Intelocking connector parts have been discontinued.
