Touch Audio VD300WR Owners Manual
Installation
7.2"
7.67"
5.9"
7.08"
5.86"
8.86"
2.16 "
2.16 "
Accessories included:
• Wireless Remote
• FM Antenna (Pig Tail)
• RCA Cable (Video)
• Batteries (x2)
• Mounting Screws (x6)
• Wiring Harness (DC Power and Speakers)
• DC Power Extension (Red and Black Wires)
Mounting the Touch Audio:
1. Remove the screw covers.
2. Connect all wires and test the radio.
Connecting the speakers wrong will cause distortion and damage the power amplifier.
3. Mount the radio in the wall or cabinet.
4. Screw the unit in place, replace screw covers.
Fig. 5
