Touch Audio VD300WR Owners Manual
System
Safety Information
The “WARNING” symbol above is a sign that a service or maintenance procedure has a safety risk involved and may
cause death or serious injury if not performed safely and within the parameters set forth in this manual.
Always wear eye protection when performing service or maintenance to the vehicle. Other safety equipment to
consider would be hearing protection, gloves and possibly a full face shield, depending on the nature of the service.
This manual provides general service and maintenance procedures. Many variables can change the circumstances
of the service procedure, i.e., the degree of difficulty involved in the service operation and the ability level of the
individual performing the operation. This manual cannot begin to plot out procedures for every possibility, but
will provide the general instructions for effectively servicing the vehicle. In the event the skill level required or the
procedure too difficult, a certified technician should be consulted before performing the necessary service. Failure
to correctly service the vehicle may result in death, injury or voiding the warranty.
System Specifications
Feature Specification
Laser 650um Wave Length
Video Auto/NTSC
Frequency Response 20 Hz - 20 KHz
Signal/Noise Ratio >95 dB
Dynamic Range >80 dB (1 KHz)
Video Out
Output Level - 1vp-p
Load Impedance - 75 Imbalance
Negative Polarity
Power Supply DC 12-14.4 V
Power Consumption <50 W
Dimensions (WxHxD) 218mm x 185mm x 169mm
Weight Approx. 2kg
AM Frequency AM 520 ~ 1710 KHz
FM Frequency FM 87.5 ~ 108 MHz
WB CH1 - CH7 MHz
Frequency Range
CH1 - 162.400 MHz
CH2 - 162.425 MHz
CH3 - 162.450 MHz
CH4 - 162.475 MHz
CH5 - 162.500 MHz
CH6 - 162.525 MHz
CH7 - 162.550 MHz
Output Power 200 W PMPO
