MAX Oil-Fired Boiler
Page 23
SECTION 7.
Part Numbers
Part Number Description
70-002
Boiler Body 75/100/120
71-002
Boiler Body 140/165
70-160
Control Center (manifold only)
70-184
Beckett AF2 (for direct vent MAX DV)
72-184
Beckett AF2 (for chimney vent MAX only
70-185
Carlin EZ-1 Elite Burner
(for direct vent MAX DV)
72-185
Carlin EZ-1 Elite Burner
(for chimney vent MAX only)
70-552
Riello BF-5 (for direct vent MAX DV)
70-375
Beckett AFG (MAX 140)
70-376
Beckett AFG (MAX DV 140)
70-377
Beckett CF375 (MAX 165)
70-378
Beckett CF375 (MAX DV 165)
70-202
Z-Flex, stainless steel, 5" x 15'
70-204
Z-Flex, aluminum, steel, 4" x 15'
70-212
Z-Flex, stainless steel, 5" x 10'
70-214
Z-Flex, aluminum, 4" x 10'
70-274
MAX DV Control Center (boxed)
72-274
MAX Control Center (boxed)
70-306
Left Side, Jacket 75/100/120
71-306
Left Side, Jacket 140/165
70-314
Right Side, Jacket 75/100/120
71-314
Right Side, Jacket 140/165
70-318
Top Panel, Jacket 75/100/120
71-318
Top Panel, Jacket 140/165
70-322
Top Cover, Jacket 75/100/120
71-322
Top Cover, Jacket 140/165
70-326
Rear Plate, Jacket 75/100/120
71-326
Rear Plate, Jacket 140/165
70-122
Front Panel, Jacket 75/100/120
71-122
Front Panel, Jacket 140/165
c.
Blow down domestic water piping and heater
using the same principle to prevent damage
to it by freezing.
4.
Contact service personnel before remodeling, for
annual servicing/maintenance, before extended
periods of shutdown, and before start-up.
SERVICE PERSONNEL
Name ______________________________________
Address ____________________________________
__________________________________________
Telephone __________________________________
Caution
Do not tamper with the unit or controls - call
Service Personnel.
6B. General
1.
To avoid unnecessary expense and inconvenience,
your boiler should be serviced at least once a
year by a qualified service person.
2.
Always keep the fuel tank full, especially in
summer to prevent moisture condensing on the
inside surface of the tank.
3.
The oil burner motor is permanently lubricated -
no oiling is necessary.
4.
Keep a regular check on the direct vent terminal
for any blockage by leaves or other debris. Your
boiler relies on an adequate supply of air for
clean combustion and any obstruction of the air
inlet could result in poor combustion and fuel
odors.
5.
If you experience problems with your boiler
check the following points before calling the
service person:
a.
Check that there is fuel in the tank.
b. Check the room thermostat is set high
enough.
c.
Check the service switch near the boiler is in
the ON position.
d. Check that the burner control reset button, if
open (popped) reset by pushing button in. If
burner does not complete a proper start and
heat sequence DO NOT RESET SWITCH A
SECOND TIME until a qualified service
person has inspected the burner.
e.
Check that the manual reset control has not
opened (popped). Do not reset more than one
time without having the boiler inspected by a
qualified service person.
