Cascading multiple boilers
You can cascade up to eight NeoTherm boilers together. One boiler becomes the Master and
the other boilers become the Slaves.
Note: The system sensor and outdoor sensor will need to be wired to the Master boiler only.
The input from these sensors is used by the Master control to control the modulation rate of all
of the operating boilers it is connected to. If the Outdoor sensor is not used, the alarm light on
the SOLA control will be on, and the alarm contacts will close.
Lead Lag Set Point
Navigation
•
Home screen, press “I” Info/Install button
•
Scroll to “Advanced Set Up”, press OK
•
Scroll down to highlight “Lead Lag Configure”, press OK
•
“Lead Lag Master Configure” is highlighted, press OK
•
Scroll down to “Setpoint”, press OK
•
Adjust the setpoint, press OK (see bottom of page 5)
Lead Lag Outdoor Reset
Navigation
•
Home screen, press “I” Info/Install button
•
Scroll to “Advanced Set Up”, press OK
•
Scroll down to highlight “Lead Lag Configure”, press OK
•
Scroll Down to highlight “Lead Lag Outdoor Reset”, press OK
Note: The Outdoor Reset is already Enabled. You may choose to adjust the other set points
•
Use the Down button to highlight each parameter you wish to change
•
Press OK, change the desired set point, press OK.
•
Use the Down button to choose your next set point, make adjustments, press OK
Warm Weather Shut Down
Navigation
•
Home screen, press “I” Info/Install button
•
Scroll to “Advanced Set Up”, press OK
•
CH Configure, Press OK
•
Use the Down button to highlight “Warm Weather Shutdown”, press OK
•
Highlight Warm Weather Shutdown Setpoint”, press OK
•
Adjust the set point, press OK
