Single Boiler Set Up
Note:
When installing a single boiler, the system sensor supplied with the boiler is not needed. The
system sensor will be needed when cascading multiple boilers together.
The Outdoor sensor supplied with the boiler must be installed. If not, the alarm light on the SOLA
control will be on and the alarm contacts will close.
Single Boiler CH Set Point
Navigation
•
Home screen Press “I” Info/Install
•
“Quick Start” should be highlighted, press OK.
•
CH Setpoint should be highlighted, press OK.
•
Using the arrows and OK button, adjust the set point. (see the bottom of page 5).
After pressing the round OK button to confirm a set point, the display will go back to the “Quick
Start” screen. You can now select and adjust other parameters from this screen. The screen will time
out after 8 minutes of no activity, and return back to the Home Screen.
Single boiler DHW Set Point
Navigation
•
Home screen, Press “I” Info/Install
•
“Quick Start” should be highlighted, press OK
•
Use the Down arrow button to Highlight “DHW set point”, press OK.
•
Using the arrow and OK button, adjust the set point. (see the bottom of page 5).
•
Press OK
Single boiler Outdoor reset
Note:
The Outdoor reset is Enabled from the factory. (No further steps needed).
