LAARS Mighty Therm2 MT2P (Sizes 500–2000 MBTU/h) - Install and Operating Manual - Manual (Page 27)

MT2P Pool Heater Page 27
IItem
Description
Size
Size
Size
Size
Size
Size
Size
500
750
1000
1250
1500
1750
2000
Manifold, 4 Burner/Orifice, Left
L2012600 (2)
L2012600 (2)
L2012600 (2)
L2012600 (4)
Manifold, 4 Burner/Orifice, Right
L2012700 (1)
L2012700 (1)
L2012700 (1)
L2012700 (2)
54
Assembly
, 3 Burner
L2012200 (2)
L2012200 (3)
L2012200 (5)
L2012200 (2)
L2012200 (3)
L2012200 (2)
Assembly
, 4 Burner
L2012500 (3)
L2012500 (3)
L2012500 (3)
L2012500 (4)
55
Orifice, Gas, Natural
L2013000 (6)
L2013000 (9)
L2013000 (12)
L2013000 (15)
L2013000 (18)
L2013000 (21)
L2013000 (24)
Orifice, Gas, Propane
L2012400 (6)
L2012400 (9)
L2012400 (12)
L2012400 (15)
L2012400 (18)
L2012400 (21)
L2012400 (24)
56
Gasket, 3 Burner
S2012700 (2)
S2012700 (3)
S2012700 (5)
S2012700 (2)
S2012700 (3)
Gasket, 4 Burner
S2012500 (3)
S2012500 (3)
S2012500 (3)
57
Ignitor
, Hot Surface w/Gasket
2400-286 (1)
2400-286 (1)
2400-286 (2)
2400-286 (2)
2400-286 (2)
2400-286 (2)
2400-286 (2)
Heat
exchanger Components -
See Figure 16
58
Flow Switch
E0013000
E0013000
E0013000
E0013000
E0013000
E0013000
E0013000
59
Low W
ater Cutof
f
(optional)
E2076500
E2076500
E2076500
E2076500
E2076500
E2076500
E2076500
60
Gauge,
Temperature/Pressure
A0079000
A0079000
A0079000
A0079000
A0079000
A0079000
A0079000
61
Tee,
Adapter
, Outlet, Cast Iron
20130001
20130001
20130001
20130001
20130001
20130001
20130010
Tee,
Adapter
, Outlet, Bronze
20150302
20150302
20150302
20150302
20150302
20150302
20150313
62
Relief V
alve, 75 PSI
A0063300
A0063300
A0063600
A0063600
A0063600
A0063600
A0002700
63
Flange, Connection, Cast Iron
10391302
10391302
10391302
10391302
10391302
10391302
10391302
Flange, Connection, Bronze
20255401
20255401
20255401
20255401
20255401
20255401
20255401
64
Gasket, Connection Flange
S0063700 (2)
S0063700 (2)
S0063700 (2)
S0063700 (2)
S0063700 (2)
S0063700 (2)
S0063700 (2)
65
Cover
, In/Out, Glass-Lined Cast Iron
10364504
10364504
10364504
10364504
10364504
10364504
10364504
Cover
, In/Out, Bronze
10364501
10364501
10364501
10364501
10364501
10364501
10364501
66
Gasket, Header/Cover
S0095100 (2)
S0095100 (2)
S0095100 (2)
S0095100 (2)
S0095100 (2)
S0095100 (2)
S0095100 (2)
66A
Gasket
(Bronze Headers)
S0024600
S0024600
S0024600
S0024600
S0024600
S0024600
S0024600
67
W
ater Barrier
, Inlet/Outlet
20230101
20230101
20230101
20230101
20230101
20230101
20230101
68
Baffle, W
ater Deflector
, Inlet
10338300
10338300
10338300
10338300
10338300
10338300
10338300
69
W
ell, Immersion,
Temperature Control
E2058300
E2058300
E2058300
E2058300
E2058300
E2058300
E2058300
70
Cover
, Return, Glass-Lined Cast Iron
10364300
10364300
10364300
10364300
10364300
10364300
10364300
Cover
, Return, Bronze
10364301
10364301
10364301
10364301
10364301
10364301
10364301
71
Pump Housing, Glass-Lined Cast Iron
S2056900
S2056900
S2056900
S2056900
S2056900
S2056900
S2056900
Pump
Housing,
Bronze
S0024600
S0024600
S0024600
S0024600
S0024600
S0024600
S0024600
72
Baffle, Dif
fuser
, Pump Housing Inlet
10338400
10338400
10338400
10338400
10338400
10338400
10338400
73
Mixing V
alve
A21
14601
A21
14602
A21
14602
A21
14602
A21
14603
A21
14604
A21
14605
electrical Components -
See Figure 17
75
DPDT
Switch
E0109200
E0109200
E0109200
E0109200
E0109200
E0109200
E0109200
75A
DPDT
Switch
E2056300
E2056300
E2056300
E2056300
E2056300
E2056300
E2056300
78
Control, Gas Ignition,
Three
Try
(standard)
E2313900 (1)
E2313900 (1)
E2313900 (2)
E2313900 (2)
E2313900 (2)
E2313900 (2)
E2313900 (2)
Control, Gas Ignition, Single
Try
(CSD-1 option)
E2107300 (1)
E2107300 (1)
E2107300 (2)
E2107300 (2)
E2107300 (2)
E2107300 (2)
E2107300 (2)
