4 MBC-M-BA-e-1312
1 Technical data
KERN MBC 15K2DM MBC 20K10M
Weighing range (max) 6 kg / 15 kg 20 kg
Minimum load (Min) 40 g / 100 g 200 g
Readability (d) 2 g / 5 g 10 g
Verification value (e) 2 g / 5 g 10 g
Reproducibility 2 g / 5 g 10 g
Linearity ± 2 g / 5 g 10 g
Display LCD with 25mm high digits
Recommended
adjustment weight, not
added (class)
15 kg
(M1)
20 kg
(M1)
Stabilization time (typical) 2 sec.
Warm-up time 10 min
Operating temperature
+ 0° C …. + 40° C
Humidity of air max. 80 % (not condensing)
Input Voltage 220 V
– 240 V AC, 50 Hz
Auto Off After “x“ min adjustable without load change
Dimensions fully mounted
(W x D x H) mm 890 x 460 x 170
(incl. integrated height measuring device)
Dimensions display unit
(BxHxT) mm
200 x 125 x 58
Baby weighing pan
(WxDxH) mm
600 x 280 x 55
Weight kg (net) 5.5
Rechargeable battery
operation
optional
Verification according to
2009/23/EG
Medical grade III
Medical product in
accordance with
93/42/EEC
Category I with measuring function
Height measuring rod,
(optional)
Measuring range: 40 - 80 cm
