10 Preload, Deadload and Overload settings
Kern model
max. Preload* (kg)
* = additional initial load
Deadload** (kg)
**= already applied
preload
Center Overload
Protection circa
(kg) Corner Overload
Protection circa
(kg) Loadcell
Capacity (kg)
KXP 600V20SM 300kg 90 NA N/A 500kg
KXP 600V20M 300kg 120 NA N/A 500kg
KXP 1500V20SM 750kg 90 NA N/A 1000kg
KXP 1500V20M 750kg 120 NA N/A 1000kg
KXP 3000V20M 1500kg 120 NA N/A 1500kg
Platform type Platform dimension
(mm) Loadcell TC Class Max E
max
E
min
Y n Dead-load T
min
T
max
Cable-
Type No. Preload -1 -4 -3 (kg)
-5 -6
length
(kg) (kg) (g) (m)
KXP 600V20SM 1000x1000x80 CZL-8C-0.5T D09-03.19 C3 300 500 0 10000 3000 300kg -10 40 5
KXP 600V20M 1500x1250x80 CZL-8C-0.5T D09-03.19 C3 300 500 0 10000 3000 300kg -10 40 5
KXP 1500V20SM 1000x1000x80 CZL-8C-1T D09-03.19 C3 750 1000 0 10000 3000 750kg -10 40 5
KXP 1500V20M 1500x1250x80 CZL-8C-1T D09-03.19 C3 750 1000 0 10000 3000 750kg -10 40 5
KXP 3000V20M 1500x1250x80 CZL-8C-1.5T D09-03.19 C3 1500 1500 0 10000 3000 1500kg -10 40 5
