14 KFA V20-IA-e-1312
9 Service documentation
This chapter is only intended for a balance specialist!
The weighing beams are fitted with a DMS weigh cell at each corner.
The analogue-digital transformation occurs in the display unit. Also all
the balance and country-specific data are stored there.
9.1 Overview, setting regulation, tolerances
Testing and setting regulations:
Capacity 600 kg 1500 kg
Readability 200 g 500 g
Min 4 kg 10 kg
Max 600 kg 1500 kg
1/3 corner load 200 kg 500 kg
Tolerance 200 g 500 g
Verification data and tolerances as per OIML:
-1
-0,75
-0,5
-0,25
0
0,25
0,5
0,75
1
0 500 1000 1500
[kg]
[g]
-0,4
-0,3
-0,2
-0,1
0
0,1
0,2
0,3
0,4
0 100 200 300 400 500 600
[kg]
[g]
600kg
1500kg
