11 Preload, Deadload and Overload settings
Kern model max. Preload* (kg)
* = additive preload
Deadload** (kg)
**= already applied
preload
Center Overload
Protection circa (kg) Corner Overload
Protection circa (kg) Loadcell
Capacity (kg)
KFD 600V20M 0 100kg 0 0 500 kg
KFD 600V20LM 0 160kg 0 0 500 kg
KFD 1500V20M 0 100kg 0 0 1000 kg
KFD 1500V20LM 0 160kg 0 0 1000 kg
Platform type Platform dimension
(mm) Loadcell TC Class Max E
max
E
min
Y n Dead-load T
min
T
max
Cable-
Type No. Preload -1 -4 -3 (kg)
-5 -6
length
(kg) (kg) (g) (m)
KFD 600V20M 1000x1000 H8C D09-03.19R2 C3 0 500kg 0 15000 3000 100kg -10 40 4
KFD 600V20LM 1200x1200 H8C D09-03.19R2 C3 0 500kg 0 15000 3000 160kg -10 40 4
KFD 1500V20M 1000x1000 SQB TC6911 C3 0 1000kg 0 10000 3000 100kg -10 40 3
KFD 1500V20LM 1200x1200 SQB TC6911 C3 0 1000kg 0 10000 3000 160kg -10 40 3
