KERN & SOHN FKB 65K1A - Manual (Page 6)

KERN FKB 30K5DA FKB 36K0.5A FKB 60K2A
Readability (d) 5 g/10 g 0.5 g 2 g
Weighing range (max) (d) 15 kg/30 kg 36 kg 60 kg
Taring range (subtractive) 15 kg/30 kg 36 kg 60 kg
Reproducibility 5 g/10 g 0.5 g 2 g
Linearity 15 g/30 g 1.5 g 6 g
Minimum unit weight at
piece counting
2 g 1 g 4 g
Warm-up time 10 minutes 2 hours 2 hours
Reference quantities at
piece counting
5, 10, 20, 25, 50
Weighing Units Details „Weighing units“ see chpt. 9.3
Recommended adjustment
weight, not added (class)
Details for „Selection of the
Adjustment weight“ in ch. 9.3
30 kg ( F2 ) 30 kg ( F1 ) 60 kg ( F2 )
Stabilization time (typical) 2 sec. 3 sec. 3 sec.
Operating temperature +5°C... + 35° C
Humidity of air max. 80 % (not condensing)
Housing (B x D x H) mm 350 x 390 x 120
Weighing plate mm 340 x 240
Weight kg (net) 6,5
Electric Supply 220V-240V AC, 50 Hz / 9 V DC, 300 mA
Battery operation 9 V compound battery (optional)
Rechargeable battery (optional)
Operating time 48 h with display background
illumination/ loading time 10 h
Interface RS232
Underfloor weighing standard
FKB_A-BA-e-1513 6
