LC-202P/LC-208P
Quick Start Guide
5.5 Host Computer Wiring Connections
The wiring connections between the Host Computer and the access control/elevator control network
are thoroughly described in the PXL-250/SB-293 Technical Reference Manual (P/N 01836-003)
and the PXL-250 Quick Start Guide (P/N 01835-002). Please refer to these documents for
information regarding host computer/network connections.
6.0 Elevator Reader Responses to Access Control Events
During day-to-day activity, the reader in the elevator car will respond to access control events in a
specific manner. Refer to Table 10 for a summary of the Reader’s LED and beeper actions during
access control events.
Table 10: Reader Responses to Access Control Events
Event LED Status Beeper Status
waiting for card presentation displays a steady Amber LED silent
upon card presentation flashes a Green LED one short beep
