KENTON PLUGSTATION USERS MANUAL
77
The MIDI specification is designed to assist end users who wish to write support software, mixer maps, VST
scripts, Logic Environment pages and SONAR panels for PLUGSTATION. Please feel free to use the data in
this section to assist you.
This MIDI spec is subject to change over time, as new features or adjustments may be made to
PLUGSTATION to improve functionality. Newer versions of the spec will be posted to the KENTON website.
PLUGSTATION sysex spec 27/06/2001
The following six bytes apply to all messages (except o/s update)
Sysex Header
Byte valid range description
F0h start sysex
00h KE ID byte #1
20h KE ID byte #2
13h KE ID byte #3
0Ah product ID
dev_num 00h-0Fh device number
The following bytes apply to some messages where:-
Change parameter message the specified parameter is updated with the supplied data byte
adr_hi (byte#7) description adr_lo (byte #8) description
00h-03h plg card 1-4 parameters plg_para_num plg parameter number
08h global parameters glob_para_num global parameter number
09h Y board parameters y_para_num Y board parameter number
0Ah Z board parameters z_para_num Z board parameter number
Request parameter message the value of the specified parameter is returned by PLUGSTATION in
all parameters are sent
adr_hi (byte#7) description adr_lo (byte #8) description
70h edit buffer para request 00h-03h plg card 1-4 parameters
70h edit buffer para request 08h global parameters
70h edit buffer para request 09h Y board parameters
70h edit buffer para request 0Ah Z board parameters
71h prog dump request prg_num program number
79h global + y + z dump request 00h global + y + z parameters
Program dump message
adr_hi (byte#7) description adr_lo (byte #8) description
10h program dump prg_num program number
18h global + y + z 00h dummy byte
