Small, outdoor cyi, Visor and non-visor – Cooper Lighting Ametrix ADY071451 User Manual
Page 4
4
1
2 "
114.30
Installation Instructions
Vault w/ visor
C-Scroll w/ visor
Roundel w/ visor
These installation instructions are valid with the above Ametrix styles
Mounting Plate Dimensions
in [mm]
ADY071451 REV A(ECN070306)
Warning
: Before starting any work ensure
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Small, OUTDOOR
CYI
(Continuous, Yoke mount, Integral ballast)
Visor and Non-Visor
(Dimensions are valid for both power, end and center(shown) hub mounting plates)
Sheet 4 of 5
Front View of
mounting plate
Side View
194.64
21
7
"
Standard Length
6.35
"
4
1
32
2
27
32 "
72.39
5
1
4 "
133.35
Top View
2"
50.80
3
9
16 "
90.42
