Zoom H4n - Manual (Page 76)

Tuner
TIC) >
075
The H4n features a tuner with multiple tuning modes.
3-01-1 Tuner
Not available during recording and playback.
NOTE:
• The input source signals selected at the present become
the tuning target.
• Operating under 4CH mode, at Step 4 select
and select the input source, and then continue to steps 5.
HINT:
1
Press.
2
Select and press.
3
Select and press.
4
Select and press.
Low
The name of the [NOTE] shows the
nearest one to the input signals.
The indicator shows the input signals are higher or lower than the
‘NOTE’ described below.
Both marks light on when the inputs signals match the ‘NOTE’.
These dots show how
much gaps exist between
the input signals and the
indicated NOTE.
High
5
Tuning.
Press the [MENU] button for
more than 2 seconds, and start
operation from the top screen.
Ref. ☞
Relationship between string numbers and notes P.078
Display of tuning
