Hydro Hose and Pump Assembly- Parts List for Figure 4
Ref.
No. Part No.
Description
Qty.
1
00012157 Washer lock 3/8 zinc
2
2
00012428 Washer lock 3/8 zinc
8
3
00020628 Key, 3/16" x 7/8"
2
4
00022560 Flange Lock Hex Nut, 3/8-16
19
5
00030261 Cap, Hydro Oil Tank
1
6
01000369 Hex Cap Screw, 3/8 -16 x 1.25
2
7
01000372 Carriage Bolt, 3/8-16 x .75 LG.
4
8
01000643 Carriage Bolt, 3/8-16 x 1
9
9
01002010 Carriage Screw, 3/8-16 x 1.25
4
10 01001618 Strut Frame
2
11 01004192 Oil Pan Drain Plug w/ Seal
1
12 01006948 Hydro Wheel Motor Backup Plate
2
13 01007309 Hex Nut, 3/8-24
2
14 01007791 Socket Head Capscrew, 1/2-13; 3-1/2
8
15 01009775 Hydro Motor Spacer
2
16 02000296 Grommet Fitting, .54 ID x .78 OD
1
17
02000841
Socket Low Head Cap Screw, 1/4-20 x 0.75
2
18
02000905
Hydro Pump, BDP-12, RH
1
01009631
Kit, Fan
1
19
02000906
Hydro Pump, BDP-12, LH
1
01009631
Kit, Fan
1
20
02001150
Hydraulic In-Tank Filter includes:
1
02001161
Filter
1
21
02001151
Fitting Elbow Spur, 5/8 x 1/2
1
22
02001156
Hydraulic Tank Assembly
1
23
02001160
Fitting Elbow, 9/16 x 1/2
4
24
02001169
Fan Pump Shroud
2
25
02001172
Hydro Pump Pulley
2
26
02001176
Short Pressure Hose Assembly
2
27
02001177
Long Pressure Hose Assembly
2
28
02001180
Fitting Elbow, 3/4 x 1/2
1
29
02001489
Hydro Motor Frame Assembly
1
30
02001496
Hydro Motor, Left Hand Assembly w/ Brake & Drum
1
31
02001497
Hydro Motor, Right Hand Assembly w/ Brake & Drum
1
32
02001715
Adaptor Fitting, 8 x 10
4
33 01000215 Hose Clamp
12
34
--
Fuel Hose, .50 ID x .75 OD (in inches)
79
35
02002003
Adaptor, 8 x 8
4
36
750-3119 Spacer .406 ID x 1.0 OD
2
37
02001175
Tee Fitting, 1/2
2
NOTE: Lubricant,
02002058
Quarts, 2.00
